16 ENGLISH

Positive stopper

The positive stopper is useful for setting the designated

angle quickly. Turn the positive stopper so that the

arrow on it points your desired bevel angle (around

22.5°/45°/60°). Loosen the lever and then tilt the tool

base until it stops. The position where the tool base

stops is the angle you set with the positive stopper.

Tighten the lever with the tool base at this position.

►

Fig.12:

1.

 Positive stopper

-1°-bevel cutting

To perform -1°-bevel cutting, loosen the clamping

screws and press the levers toward the direction of the

arrow in the figure. Then set the bevel angle to -1° and

tighten the clamping screws.

►

Fig.13:

1.

 Lever

Sighting

For straight cuts, align the 0° position on the front of the

base with your cutting line. For 45° bevel cuts, align the

45° position with it.

►

Fig.14:

1.

 Cutting line (0° position)

2.

 Cutting line

(45° position)

Lighting the lamp

CAUTION:

Do not look in the light or see the

source of light directly.

To turn on the lamp without running the tool, pull the

switch trigger without pressing the lock-off button.

To turn on the lamp with the tool running, press and hold

the lock-off button and pull the switch trigger.

The lamp goes out 10 seconds after releasing the switch trigger.

►

Fig.15:

1.

 Lamp

NOTE:

 Use a dry cloth to wipe the dirt off the lens of

the lamp. Be careful not to scratch the lens of lamp, or

it may lower the illumination.

Electric brake

This tool is equipped with an electric blade brake. If the

tool consistently fails to quickly stop the circular saw

blade after switch lever release, have tool serviced at a

Makita service center.

CAUTION:

The blade brake system is not a

substitute for blade guard. NEVER USE TOOL

WITHOUT A FUNCTIONING BLADE GUARD.

SERIOUS PERSONAL INJURY CAN RESULT.

Electronic function

The tools equipped with electronic function are easy to

operate because of the following feature(s).

Soft start feature

Soft start because of suppressed starting shock.

Constant speed control

Electronic speed control for obtaining constant speed.

Possible to get fine finish, because the rotating speed is

kept constant even under load condition.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Hex wrench storage

When not in use, store the hex wrench as shown in the

figure to keep it from being lost.

►

Fig.16:

1.

 Hex wrench

Installing sub base

Install the sub base and tighten the clamping screws

securely as shown in the figure.

Always use the tool with the sub base unless when

using the guide rail.

►

Fig.17:

1.

 Clamping screw

2.

 Sub base

Installing or removing circular saw

blade

CAUTION:

Be sure the circular saw blade is

installed with teeth pointing up at the front of the

tool.

CAUTION:

Use only the Makita wrench to

install or remove the circular saw blade.

1.

  Loosen the lever on the depth guide and move the

base down.

►

Fig.18:

1.

 Lever

2.

  Install the inner flange, ring (country specific),

circular saw blade, outer flange and hex bolt. At this

time, align the direction of the arrow on the blade with

the arrow on the tool.

For tool without the ring

►

Fig.19:

1.

 Hex bolt

2.

 Outer flange

3.

 Circular saw

blade

4.

 Inner flange

5.

 Arrow on the circular

saw blade

6.

 Arrow on the tool

For tool with the ring

►

Fig.20:

1.

 Hex bolt

2.

 Outer flange

3.

 Circular saw

blade

4.

 Ring

5.

 Inner flange

6.

 Arrow on the

circular saw blade

7.

 Arrow on the tool

3.

  Press the shaft lock fully so that the circular saw

blade cannot revolve and use the hex wrench to tighten

the hex bolt.

►

Fig.21:

1.

 Shaft lock

2.

 Hex wrench

3.

 Loosen

4.

 Tighten

To remove the circular saw blade, follow the installation

procedure in reverse.
