Makita DHS680Z - Инструкция по эксплуатации - Страница 5

5

•

Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).


ENH101-18

For European countries only

EC Declaration of Conformity

Makita declares that the following Machine(s):

Designation of Machine:
Cordless Circular Saw
Model No./ Type: DHS680

Conforms to the following European Directives:

2006/42/EC

They are manufactured in accordance with the following
standard or standardized documents:

EN60745

The technical file in accordance with 2006/42/EC is
available from:

Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium


18.3.2014

000331

Yasushi Fukaya

Director

Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium

GEA010-1

General Power Tool Safety
Warnings

WARNING Read all safety warnings and all

instructions.

 Failure to follow the warnings and

instructions may result in electric shock, fire and/or
serious injury.

Save all warnings and instructions for
future reference.

GEB060-8

CORDLESS CIRCULAR SAW
SAFETY WARNINGS

Cutting procedures

1.

DANGER: Keep hands away from cutting

area and the blade. Keep your second hand
on auxiliary handle, or motor housing.

 If both

hands are holding the saw, they cannot be cut by
the blade.

2.

Do not reach underneath the workpiece.

 The

guard cannot protect you from the blade below
the workpiece.

3.

Adjust the cutting depth to the thickness of
the workpiece.

 Less than a full tooth of the blade

teeth should be visible below the workpiece.

4.

Never hold piece being cut in your hands or
across your leg. Secure the workpiece to a
stable platform.

 It is important to support the

work properly to minimize body exposure, blade
binding, or loss of control.

A typical illustration of proper hand support
and workpiece support.

000161

5.

Hold the power tool by insulated gripping
surfaces only, when performing an operation
where the cutting tool may contact hidden
wiring.

 Contact with a "live" wire will also make

exposed metal parts of the power tool "live" and
could give the operator an electric shock.

6.

When ripping, always use a rip fence or
straight edge guide.

 This improves the accuracy

of cut and reduces the chance of blade binding.

7.

Always use blades with correct size and
shape (diamond versus round) of arbour
holes.

 Blades that do not match the mounting

hardware of the saw will run eccentrically,
causing loss of control.

8.

Never use damaged or incorrect blade
washers or bolt.

 The blade washers and bolt

were specially designed for your saw, for
optimum performance and safety of operation.

Kickback causes and related warnings

−

  kickback is a sudden reaction to a pinched, bound

or misaligned saw blade, causing an uncontrolled
saw to lift up and out of the workpiece toward the
operator;

−

  when the blade is pinched or bound tightly by the

kerf closing down, the blade stalls and the motor
reaction drives the unit rapidly back toward the
operator;

−

  if the blade becomes twisted or misaligned in the

cut, the teeth at the back edge of the blade can dig
into the top surface of the wood causing the blade
to climb out of the kerf and jump back toward the
operator.

Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided
by taking proper precautions as given below.
