The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-5.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
12.05.2014

Assembly

Mounting/Replacing the Saw Blade



Before any work on the machine itself, pull the mains
plug.



When mounting the saw blade, wear protective gloves.

Danger of injury when touching the saw blade.



Only use saw blades that correspond with the charac-
teristic data given in the operating instructions.



Do not under any circumstances use grinding discs as
the cutting tool.

Selecting a Saw Blade

An overview of recommended saw blades can be found at the
end of this manual.

Removal of the Saw Blade (see figure A)

For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.

– Press the spindle lock button

5

 and keep it pressed.



The spindle lock button 5 may be actuated only when
the saw spindle is at a standstill.

Otherwise, the power

tool can be damaged.

– With  the  Hex  key

11

, unscrew the clamping bolt

20

 turning

in rotation direction



.

– Tilt back the retracting blade guard

13

 and hold firmly.

– Remove the clamping flange

21

 and the saw blade

22

 from

the saw spindle

24

.

Mounting the Saw Blade (see figure A)

For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.

– Clean the saw blade

22

 and all clamping parts to be assem-

bled.

– Tilt back the retracting blade guard

13

 and hold firmly.

– Place  the  saw  blade

22

 on to the mounting flange

23

. The

cutting direction of the teeth (direction or arrow on saw
blade) and the direction-of-rotation arrow on the blade
guard

18

 must correspond.

– Mount  the  clamping  flange

21

 and screw in the clamping

bolt

20

 turning in rotation direction



. Observe correct

mounting position of mounting flange

23

 and clamping

flange

21

.

– Press the spindle lock button

5

 and keep it pressed.

– With  the  Hex  key

11

, tighten the clamping bolt

20

 turning

in rotation direction



. The tightening torque is between

6 – 9 Nm, which corresponds to hand tight plus ¼ turn.

Dust/Chip Extraction



Before any work on the machine itself, pull the mains
plug.



Dusts from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dusts can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dusts, such as oak or beech dust, are considered
as carcinogenic, especially in connection with wood-treat-
ment additives (chromate, wood preservative). Materials
containing asbestos may only be worked by specialists.
– As far as possible, use a dust extraction system suitable

for the material.

– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.

Observe the relevant regulations in your country for the mate-
rials to be worked.



Prevent dust accumulation at the workplace.

Dusts can

easily ignite.

Mounting the Extraction Adapter (see figure B)

Attach the extraction adapter

25

 onto the sawdust ejector

17

until it latches. A vacuum hose with a diameter of 35 mm can
be connected to the extraction adapter

25

.



The extraction adapter may not be mounted when no
external dust extraction is connected.

Otherwise the ex-

traction channel can become clogged.



Do not connect a dust bag to the extraction adapter.

Otherwise the extraction system can become clogged.

To ensure optimum extraction, the extraction adapter

25

must be cleaned regularly.
