16

 | English

2 609 932 939 | (21.5.14)

Bosch Power Tools

1

On/Off switch

2

Lock-off button for On/Off switch

3

Thumbwheel for speed preselection  (GKS 55 GCE)

4

Auxiliary handle (insulated gripping surface)

5

Spindle lock button

6

Scale for mitre angle

7

Wing bolt for parallel guide

8

Wing bolt for bevel-angle preselection

9

Cutting mark, 0 °

10

Cutting mark, 45 °

11

Hex key

12

Parallel guide *

13

Retracting blade guard

14

Lever for retracting blade guard

15

Base plate

16

Wing bolt for bevel-angle preselection

17

Sawdust ejector

18

Blade guard

19

Handle (insulated gripping surface)

20

Clamping bolt with washer

21

Clamping flange

22

Saw blade *

23

Mounting flange

24

Saw spindle

25

Extraction adapter *

26

Clamping lever for cutting-depth preselection

27

Cutting-depth scale

28

Set of screw clamps *

29

Guide rail *

30

Connection piece *

31

Vacuum hose *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-5.

Typically the A-weighted noise levels of the product are:
Sound pressure level 92 dB(A); Sound power level
103 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Cutting wood: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

,

Cutting metal: a

h

= 3.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.

Circular Saw

GKS 55

GKS 55 GCE

Article number

3 601 F64 0..

3 601 F64 9..

Rated power input

W

1 200

1 350

No-load speed

min

-1

5 200

2 100 – 5 100

Rotational speed under load, max.

min

-1

3 800

4 900

Cutting depth, max.

– for  0 °  bevel  angle
– for  45 °  bevel  angle

mm
mm

55

38.5

55

38.5

Spindle lock





Speed preselection

–



Constant electronic control

–



Reduced starting current

–



Base plate dimensions

mm

145 x 290

199 x 300

Saw blade diameter, max.

mm

160

160

Saw blade diameter, min.

mm

150

150

Blade thickness, max.

mm

1.8

1.8

Tooth thickness/setting, max.

mm

2.6

2.6

Tooth thickness/setting, min.

mm

1.8

1.8

Mounting bore

mm

20

20

Weight according to EPTA-Procedure 01/2003

kg

3.5

3.9

Protection class

 /

II

 /

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
