21

NOTE:

Cooking  time  and  temperature  in  the  table  are

advisory in nature and can vary depending on the recipe.

DISPOSAL

•

Before disposing of the old device, for safety, cut the

cord to prevent further use.

CLEANINg AND MAINTENANCE,

Рiс. D

•    Unplug the device.

•  Let the device to cool, before cleaning it.

•  Open the door completely and remove the crumb tray.

For  this,  grab  the  edge  of  the  tray,  lift  it  slightly  and

gently pull it toward you.

•  Wash  the  grid,  pan,  spit  in  a  warm  soppy  water.  They

can  be  washed  in  a  dishwasher.

  The  temperature  in

the dishwasher must not exceed 60

o

C.

•  Wipe the body of the device, crumbs tray, hobs and inner

surface (besides heating elements) with a damp soft cloth.

•    Never  immerse  the  motor  unit  into  the  water

because of the danger of electric shock.

•  Thoroughly dry all parts.

POSSIBLE PROBLEMS AND SOLUTIONS

Possible problems

Possible causes

Solutions

Device doesn’t turn on.

There is no voltage in the mains.

Unplug the device and wait for the voltage to

normalize.

There is steam

When  cooking  food  with  a  high

amount of liquid, certain amount of

steam can appear.

Be careful when opening the door, not to get

burn from steam.

Burning smell

1. There are crumbs on the tray.

2.  Fat accumulated on the grid, pan

or on the inside of the device.

1.  Clean  the  crumbs  tray  after  every  use  of

the device.

2.  Wipe the device inside (cooled) and wash

the grid and pan immediately after use.

Products must be stored in dry, ventilated warehouses at a temperature not lower than -25° C.

Only a qualified specialist of an authorized service center OURSSON AG can repair the device

PRODUCT CERTIFICATION

For information on product certification, see http://www.oursson.com or ask seller for a copy.

Specifications

MODEL

МO2305

МO2610/2620

МO3020

MO3815

MO4225

MO3030

Volume, L

23

26

30

38

42

30

Convection

-

-/+

+

+

+

+

Pan size, mm (LxW)

336,2×260

349,5×250

377,6×267

391,8x307

391,8x337

377,6×267

Power consumption, W

Max 1500

Max 2000

Max 3100

Rated voltage

220-240 V~, 50/60 Hz

Storage and transportation

temperature

up -25°C to +35°C

Operating temperature

up 5°C to 35°C

Storage, transportation and op-

eration humidity requirements

15-75% without condensate

Class of protection

I

Dimensions, mm (HxWxL)

467×350×290 489×340×322 522x360x322 540x391x343 540x426x343 522х360х338

Weight, kg

6,66

 7,14/7,54

8,52

9,67

9,85

10,5
