17

The operation of this device in any case does

not imply application of any force to it, as this

may damage the product due to user fault.

SETTINg,

Рiс. A-2

•   Place  the  device  on  a  flat  horizontal  heat  resistant

surface, high from children’s reach, keeping the dis-

tance  from  walls/furniture  as  shown  in  the  picture

A-2.  One side must be completely free.

 It is forbid

-

den to embed this device.

•   Do  not  place  the  working  device  under/near  cur

-

tains  or  other  flammable  materials,  as  this  may

cause a fire.

PRODUCT SET,

Рiс. В

Body. ........................................................................

1 pc.

1

 Enameled pan .....................................................

1 pc.

2

 Grid .....................................................................

1 pc.

3

 Handle for pan and grid ......................................

1 pc.

4

 Handle for spit. ....................................................

1 pc.

5

 Spit ......................................................................

1 pc.

6

Round pan 9”/22,8 cm

 ........................................

1 pc.

7

Tray for crumbs

 ...................................................

1 pc.

8

Fish basket.

.........................................................

1 pc.

9

Grill-basket.

 .........................................................

1 pc.

Instructions manual .................................................

1 pc.

Warranty card ..........................................................

1 pc.

ELEMENTS OF DESIgN,

Рiс. С-1

1

 Door handle

2

 Spit bracing

3

 Slots for grid and pans

4

 Door

5

 Control panel

6

 Ventilation openings

7

 Operation indicator

8

 Removable tray for crumbs

9

 Electric hobs (155 mm and 185 mm). Only for

MO3030

Inner backlight, Pic. C-1-2
Upper and lower heating elements, Pic. C-1-1

UTILIZATION

Control panel,

Рiс. С-2

Function switch,

 Рiс. С-2-4

•

STOP

position, turns off the convection / spit

operation

•

Convection (hot air circulation around the

product)

•  Spit (spit rotates, uniformly browning on all sides)

•

Convection and spit

Hobs switch,

 Рiс. С-2-5

(for MO3030 model)

•

STOP

 position, turns off the hobs

•  Turns on left hob(185mm/1000W)

•  Turns on right hob(155mm/600W)

•  Turns on both hobs

Temperature regulator,

Рiс.С-2-1

•   Adjusting  the  temperature  from  100°C  to

230°C

Р

Preparation mode switch,

Рiс.С-2-2

•

STOP

 position

•

Upper heating element (upper heating)

•  Lower heating element (lower heating)

•  Upper and lower heating elements, simultaneous

operation  of  both  upper  and  lower  heating

elements

•  Upper  heating  element  and  spit.  (For  MO2305,

MO2610 models)

•  Upper,  lower  heating  elements  and  convection

(For MO2620, MO3030 models)

•  Upper,  lower  heating  elements,  convection  and

spit (For MO2620, MO3030 models).

Timer,

Рiс.С-2-3

•

Timer, time selection from 0 up to 60 minutes.

•

STOP

position, utilized for stopping the cooking

process.

Spit construction,

Рiс. С-5

1

 Hook

2

 Clamp

3

Fastener

4

 Bayonet

5

 Motor coupling

Preparation for operation

Before  first  use,

  wipe  the  body  with  a  soft,  dry  cloth.

Wash  the  other  parts  with  warm  water  and  detergent.

Before assembling or disassembling the make sure that

the device is unplugged. Thoroughly dry all parts.

Turn  on  the  empty  device  for  15  minutes,  set  the  max

-

imum  temperature  of  230  °C  in

,  (mode

  for

MO2620/МО3030), to remove the smell of a new device.

Ventilate the room. Allow the device to cool.

Order of operation,

Рiс.C-2

1.  Make sure that the crumb tray is completely installed,

and timer knob

 is set in the

. position. Plug in

the device.

2.  Set the required temperature with the

 regulator.

3.  Turn on the timer

 for 5 minutes in the

, (

 for
