EN

6

Operation and Storage Manual of Panel Heater

to reach ‘’ON”. Confirm with “Mode”

 button. In this case function “Open

window” is switched ON.

Note:

 When the “Open window” function is enabled, the “Anti-frost” function

does not work!

Visualization on Display in “Open window” settings

:

Keyboard lock (Protection from children)

When user turns on this function, all keys of the control panel remain locked.
Hold buttons

  and “Mode”

 together for 3 seconds. The display should

show a message when this mode is activated. When user wants to turn off this
function has to hold the same button combination for 3 seconds.

Activation/deactivation: Holding

  and “Mode”

 buttons for 3 seconds

the keyboard gets locked.

To unlock the control panel, hold

  and “Mode”

buttons for 3 seconds.

Visualization on Main Display when activating and deactivating the
function “Protection from children”:

 Day and time – settings

First step or use after factory reset function

Set the current time and day by pushing the “Mode” button

 for 3 sec and

select “DAY  TIME” mode by pushing any of the buttons:

 or

. Confirm

with “Mode”  button

:

Set a schedule for the first day of the week

Select “DAY OF THE WEEK” mode by pushing any of the buttons:

 or

.

Confirm with “Mode” button

.

Select by pushing any of the buttons:

 or

 reach current day of the

week (Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, Sunday) .
Confirm with “Mode” button

.

Set time

Select “TIME” mode by pushing any of the buttons:

 or

 . Confirm

with “Mode”  button

.

The hour icon is flashing and by pushing any of the buttons:

 or

reach actual hour time. Confirm with “Mode” button

. The minute icon

is flashing and by pushing any of the buttons:

 or

 reach actual

minute time. Confirm with “Mode”  button

. (range 00.00-24.00)

Weekly program (timer) 24hours/7days

Min 300 sets of time periods

Electronic thermoregulator with weekly program (timer) 24/7 - electronic room
temperature control plus weekly timer means the product is equipped with
an electronic device, either integrated or external, which allows the product
automatically to vary its heat output over a certain time period. In relation
with a certain required level of indoor heating comfort. It allows the setting

of timing and temperature levels for a full week. During the 7-day period the
settings must allow a variation on a day-to-day basis;

 Deactivation

If the customer wants to deactivate it, he/she has to push ON/OFF

button(The heater goes into “heating” mode.) or press for 1.5 sec ON/OFF
button for OFF the heater.

 Activation

If the customer wants to set “Weekly shedule (timer)” mode- by pushing the
“Mode”  button

 for 3 sec and select “Weekly shedule”

 mode by

pushing any of the buttons:

 or

. Confirm with “Mode” button

.

There have three options:

-  CREATE PROGRAM

-  ERASE PROGRAM

-  VIEW PROGRAM

Create program

Select “Create program” by pushing any of the buttons:

 or

. Confirm

with “Mode”  button

.

1.  Set “DAY OF THE WEEK”  by pushing any of the buttons:

 or

 reach

current day of the week (Monday, Tuesday, Wednesday, Thursday, Friday,
Saturday, Sunday). Confirm with “Mode” button

.

2.  Set “TIME PERIOD” by pushing any of the buttons:

 or

 reach the

desired Start time (range 00.00-24.00). Confirm with “Mode” button

. By

pushing any of the buttons:

 or

 reach the desired End time (range

00.00-24.00).  Confirm with “Mode” button

.

3.  Set  “DESIRE TEMPERATURE”  by pushing any of the buttons:

 or

reach the desired temperature (10-30 ˚C).  Confirm with “Mode” button

.

The temperature of 22 ˚C started at 12.30 to 15.00 on Sunday. The convector
will heat till reach the settings of the next given point.

If the TIME PERIOD is empty (no time set) – visualization should be

OFF

.

- One step back – with single pushing of ON/OFF button

.

- No limit of time periods – step is 0.5 hour (30 minutes).
- Adaptive start function is switched on by default.

Erase program

Select “Erase program” by pushing any of the buttons:

 or

. Confirm

with “Mode”  button

. Select the program by pushing any of the buttons

 or

 and confirm with “Mode” button

.

Checking the schedule program

View program
