EN

Operation and Storage Manual of Panel Heater

3

English

 • Slide down the wall brace in order to detach it from the back of the body.
 • Attach firmly the wall brace onto a wall through the four screw holes.
 •

Lift the panel heater up to almost vertical position and insert the two lower
protruding parts of the braces into the two lower openings of the back
cover of the panel heater. Then lift the panel heater and insert the two upper
protruding parts of the wall braces into the two upper openings of the back
cover of the heater. Finally, put the two screws back to their places and
tighten them in order to install the panel heater firmly to the wall.

BATHROOM OPERATION

 • The panel heater must be installed in accordance with the normal trade

practices and in compliance with the national legislation (EU electricity
directives and regulations concerning special installations and places
of operation including bathrooms, shower cabins HD60364-7-701(IEC
60364-7-701:2006)).

 • In case this panel heater is to be used in a bathroom or other similar room,

the following installation requirements must be observed: the panel
heater is with IP24 protection (water drops protection). Hence it can be
installed in “Volume 2” (see the diagram below) in order to avoid the risk of
the control board (power switch and thermo regulator) being reached by
a person who is in a shower or a bathtub. The minimum distance between
the appliance and a water source should be not less than 1 meter and it
is compulsory the appliance to be wall-mounted! If you do not feel sure
about the installation of this panel heater in a bathroom, we recommend
you to consult a professional electrician.

Note

: If the above-mentioned instructions cannot be implemented, it is

recommended to install the appliance in “VOLUME 3”.

 • In wet premises the power source must be installed at a height of at least

25 cm above the floor (bathrooms and kitchens).

 •

The installation must be equipped with a safety fuse, and the distance
between the fuse contacts in disconnected condition should be at least 3 mm.

Thank you for choosing CN051 panel heater. This is a product providing
heating in winter depending on the consumers’ needs for comfortable
room temperature. If operated and taken care of properly in accordance
with these instructions, the appliance will provide you with many years of
useful operation.

OPERATION INSTRUCTIONS

 • Hold for 1.5 sec

ON/OFF

 button for OFF or ON the heater.

•

Step back

 – push the ON/OFF

 button until 1 seconds

•

Quick menu/Confirmation

 - push the Mode  button

 until 1 seconds

•

Full menu

 - hold the Mode button

 over 3 seconds

1.  Predefined functions:
Comfort mode

  ; Eco mode

 ; Sleep mode

1.1. Comfort mode

   -

with On/Off option - allows the user to set a desired

temperature when being at home. After once set it and the function is
switched On, the appliance will keep the same room temperature each time of
usage. This temperature to be set at 23°C by default.

Activation of „Comfort mode“

:

-  Push the button “Mode”

 for 3 sec and select “Comfort mode”

  by

pushing any of the buttons:

 and

 and confirm with “Mode”  button

 . After that you should set the comfort temperature

 –   by pushing any of the buttons

 or

 set the desired temperature.

Confirm with “Mode”  button

.

-  The “Comfort” mode   is activated.

Deactivation of „Comfort mode“

 :

- To deactivate the “Comfort” mode press “On/Off ”   button

 for 1.5 sec. Then

the heater turns off. The display will continue showing the set temperature. Or
press “Mode”   button

 to choose different mode.

Visualization on Display in “Comfort” mode settings

:

-  Set temperature

The display shows “Comfort” in the top and the set temperature

When the convector is in „Heating mode„ ,sign „sun„

 appears on the

display.

1.2. Eco mode

-  with On/Off option - allows the user to set a desired

temperature when being out of home. After once set it and the function is
switched On, the appliance will keep the same room temperature each time of
usage. This temperature will be set at 18°C by default.  User could also set the
time when the appliance to switch to Comfort mode.

Activation of „Eco„ mode

Push the button “Mode”

  for 3 sec and select “Eco” mode

  by pushing

any of the buttons:

 or

 and confirm with “Mode”   button

. After

that you should set the temperature – by pushing any of the buttons

 or

 set the desired temperature. Confirm with “Mode” button

.

If you want you can set the clock time:

-Select by pushing any of the buttons:

 or

 reach actual hour time.

Confirm with “Mode”   button

.

- The minute icon is flashing and by pushing any of the buttons:

 or

reach actual minute time. Confirm with “Mode”   button

(range 00.00-

24.00).
