Translation of the original operating instructions

477 296_b

15

TRANSLATION OF THE ORIGINAL

OPERATING INSTRUCTIONS

Contents

About  this  handbook........................................ 15
Product  description.......................................... 15
Scope  of  delivery............................................. 16
Safety  instructions............................................ 16
Assembly.......................................................... 17
Startup.............................................................. 17
Maintenance  and  care..................................... 18
Storage............................................................. 19
Display  indications........................................... 19
Troubleshooting................................................21
Disposal............................................................ 22
Warranty........................................................... 22
EU declaration of conformity............................ 23

ABOUT THIS HANDBOOK

Read  this  documentation  before  starting  up

the  machine.  This  is  a  precondition  for  safe

working and flawless operation.
Observe  the  safety  warnings  in  this  docu-

mentation and on the product.
This  documentation  is  a  permanent  integral

part  of  the  product  described  and  must  be

passed on to the new owner if the product is

sold.

Explanation of symbols

CAUTION!

Following  these  safety  warnings  care-

fully  can  prevent  personal  injury  and/or

material damage.

ADVICE

Special  instructions  for  greater  ease  of

understanding and improved handling.

PRODUCT DESCRIPTION

This  documentation  describes  various  different

unit models. Identify your model using the identi-

fication plate.

Product overview

Domestic water pump (Fig. A - E)

1 Clear filter cover

2 Pump housing
3 Filling screw
4 Pump outlet/pressure line connection
5 Motor housing
6 Drain screws
7 Pump inlet/suction line connection
8 Pressure line
9 Water tap

10 Elbow nipple
11 Seal
12 Connecting nipple
13 Seal
14 Suction line
15 Filter spanner
16 Filter seal
17 Filter
18 Check valve
19 Check valve seal
20 Housing seal
21 Screw-in nipple
22 Seal
23 Measuring unit float body
24 Display
25 MODE button
26 SET button

Designated use

The unit is intended for private use in the house

and garden, and is exclusively suited to pumping

clean water and rainwater.
It is suitable for:

Watering the garden and premises
Water supply in the house
Pressure increase in the water supply.
