Startup

467771_e

15

STARTUP

Safety

CAUTION!

Exclude, by suitable means, that, in the

event  of  a  fault  in  the  immersion  pump,

consequential damage is caused by floo-

ding.

Make sure that the immersion pump is stan-

ding securely or operate the immersion pump

suspended from a rope.
Make sure there is adequate clearance under

the pump.
Never  allow  the  immersion  pump  to  run

against a closed off pressure line.
When using in shafts, make sure the size is

adequate.
Always  cover  the  shaft  with  a  secure  foot-

plate.

Switching the pump on

see Fig. A - H

CAUTION!

The  immersion  pump  must  not  draw  in

any  solid  bodies.  Sand  and  other  abra-

sive materials in the conveying medium

will destroy the immersion pump.

1. Unwind the connection cable

(1)

 completely.

2. Make sure that the electrical plug connection

is mounted in the area safe from flooding.

3. Change  the  terminal  position  and  adjust  the

switching points of the float switch

(5)

 indivi-

dually.

4. Attach  the  cable  on  the  float  switch  to  the

pump housing

(4)

 securely.

➯

Recommended cable length on the float

switch approx. 120 mm

ADVICE

Use a suitable plate to ensure secure

mounting of the immersion pump on

muddy, sandy or stony ground.

5. Immerse the immersion pump in the convey-

ing medium slowly. Hold the immersion pump

at a slight angle to allow any air to esacape.

6. Vent  the  immersion  pump  DRAIN  10000

INOX/15000  INOX/DRAIN  20000  HD  at  the

venting unit

(Fig. D -9/ G-9)

.

7. Insert the mains plug into the plug socket.

➯

The immersion pump switches on auto-

matically  using  the  float  switch  when  a

specific  water  level  has  been  reached,

and switches off again if the water drops

below the switch-off height.

Switching the pump off

1 Remove the mains plug from the plug socket.

MAINTENANCE AND CARE

Disconnect  the  machine  from  the  mains

power supply before commencing assembly

and maintenance work.

Cleaning the pump

ADVICE

After  conveying  chlorine-containing

swimming pool water or fluids that leave

a residue, the pump must be flushed out

with clear water.

1. Clean  the  suction  slots  on  the  suction  foot  if

necessary with clear water.

STORAGE

ADVICE

In the event of a risk of frost, the system

must be drained completely.

DISPOSAL

Do not dispose of worn-out machines

or spent batteries (including recharge-

able batteries) in domestic waste!

The packaging, machine and accessories

are made from recyclable materials and

must be disposed of accordingly.
