Product description

14

DRAIN 10000 / 12000 / 20000 HD / 10000

(INOX) / 15000 (INOX)

Waste water
Dirty water having a max. suspended matter

proportion of 5 % and a grain size of max. 30

mm* diameter.

Any  use  not  in  accordance  with  this  designated

use shall be regarded as misuse.

* 38 mm Drain 20000 HD

Possible misuse

The  immersion  pump  must  not  be  used  conti-

nuously. They are not suitable for conveying:

Drinking water
Salt water
Foodstuffs
Aggressive media, chemicals
Corrosive,  flammable,  explosive  or  fuming

fluids
Fluids that are hotter than 35 °C
Water containing sand and abrasive fluids

SCOPE OF DELIVERY

Thermal protection

The unit is fitted with a thermal protection switch

which switches the motor off in the event of over-

heating.  The  pump  switches  on  again  automati-

cally  after  a  cooling  down  period  of  approx.  15  -

20 minutes.
Operate the unit only if the immersion pump is fully

immersed.

SAFETY INSTRUCTIONS

CAUTION!
Risk of injury!

Use the machine and the extension ca-

ble only in perfect working order. Dama-

ged equipment may not be operated.
Do not disable safety and protective de-

vices!

Children, or people who are not familiar with

the operating instructions, are not allowed to

use the machine.
Never lift, transport or suspend the unit using

the connection cable.
Unilateral modifications or conversions of the

unit are prohibited.

Electrical safety

CAUTION!
Danger  when  touching  voltage  con-

ducting parts!

Disconnect the plug from the mains if the

extension cable is damaged or severed!

We  recommend  connecting  a  RCD  (re-

sidual current operated device) having a

nominal residual current of < 30 mA.

The house mains voltage must agree with the

details  quoted  in  the  technical  data,  do  not

use any other supply voltage.
The  unit  must  only  be  operated  with  an

electrical installation in accordance with DIN/

VDE 0100, Part 737, 738 and 702 (swimming

pools). Protection must be provided by a 10 A

line protection switch and a RCCD (residual

current operated device) having a nominal re-

sidual current of 10/30 mA.
Use  only  extension  cables  that  are  suitable

for use outdoors - minimum cross-section 1.5

mm

2

. Cable drums should always be unrolled

completely.
Damaged or brittle extension cables must not

be used.

➯

Check  the  condition  of  your  extension

cable  each  time  you  start  to  use  the

equipment.

ASSEMBLY

Mounting the pressure line

see Fig. A,D and G

1. Screw the connection elbow

(7)

 into the pump

outlet.

2. Screw the combination nipple

(8)

 into the con-

nection elbow.

3. Fix a hose to the combination nipple.

ADVICE

The combination nipple can be trim-

med  to  suit  the  selected  hose  con-

nection.  Use  the  largest  possible

hose diameter.
