26

En



PLAYER SECTION

CD

• Media ........................................................................... CD, CD-R/RW

• Audio format .................................................. Audio CD, MP3, WMA

USB

• Audio format .....................................................................MP3, WMA

AUX

• Input connector ............................. 3.5 mm (1/8 ") STEREO mini jack



Bluetooth

 SECTION

•

Bluetooth

 version  .................................................................... Ver. 3.0

• Supported profile ......................................................... A2DP, AVRCP

• Supported codecs .......................................................................... SBC

• Wireless output ........................................................

Bluetooth

 Class 2

• Maximum communication distance ......... 10 m (without obstructions)



AMPLIFIER SECTION

• Maximum output power.......... 15 W + 15 W (6



 1 kHz, 10 % THD)

• Headphones

.............. 3.5 mm (1/8 in) STEREO mini jack (Impedance 16 to 32



)

• Equalizer characteristics

EQ Low (Bass)/EQ Mid (Middle)/EQ High (Treble) ..............  ±10 dB



TUNER SECTION

Tuning range

• DAB/DAB

+

 (MCR-B043D only).............. 174 to 240 MHz (Band III)

• FM ...................................................................... 87.50 to 108.00 MHz



SPEAKER SECTION

• Type .................................................................... Full range bass reflex

non magnetic shielding type

• Driver....................................................... 11 cm (4-1/2") cone type ×1

• Frequency response .......................................... 50 to 20 kHz (–10 dB)

• Dimensions (W × H × D)

.......................................... 129 (5-1/8") × 126 (4") × 251 (9-7/8") mm

• Weight ......................................................................... 1.5 kg (3.3 lbs.)



GENERAL

• Power supply .............................................................AC 230 V, 50 Hz

• Power consumption ......................................................................30 W

• Standby consumption

.................................. 3.5 W or less (NORMAL)/0.5 W or less (ECO)

• Dimensions (W × H × D)

........... (MCR-B043) 180 (7-1/8") × 130 (5-1/8") × 276 (10-7/8") mm
.............. (MCR-B043D) 180 (7-1/8") × 130 (5-1/8") × 281 (11") mm

• Weight ......................................................................... 2.6 kg (5.7 lbs.)

Specifications are subject to change without notice.

LASER SAFETY

This unit employs a laser. Due to possible eye injury, only a
qualified service person should remove the cover or attempt to
service this device.

DANGER

This unit emits visible laser radiation when open. Avoid direct eye
exposure to beam. When this unit is plugged into the wall outlet,
do not place your eyes close to the opening of the disc slot and
other openings to look into inside.

Bluetooth

•

Bluetooth

 is a technology for wireless communication between

devices within an area of about 10 meters (33 ft) employing the
2.4 GHz frequency band, a band which can be used without a
license.

•

Bluetooth

 is a registered trademark of the

Bluetooth

 SIG and is

used by Yamaha in accordance with a license agreement.

Handling

Bluetooth

 communications

• The 2.4 GHz band used by

Bluetooth

 compatible devices is a

radio band shared by many types of equipment. While

Bluetooth

compatible devices use a technology minimizing the influence of
other components using the same radio band, such influence may
reduce the speed or distance of communications and in some
cases interrupt communications.

• The speed of signal transfer and the distance at which

communication is possible differs according to the distance
between the communicating devices, the presence of obstacles,
radio wave conditions and the type of equipment.

• Yamaha does not guarantee all wireless connections between this

unit and devices compatible with

Bluetooth

 function.

SPECIFICATIONS

We, Yamaha Music Europe GmbH hereby declare that this unit
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.

Yamaha Music Europe GmbH

Siemensstr. 22-34 25462 Rellingen, Germany
Tel: +49-4101-303-0
