   DANGER!

This measurement is not suitable for

the detection of dangerous mains

voltages.

Even if the display

[1]

 does not flash

during testing or measurement and no

signal beep is emitted, a dangerously

high voltage  (> 33 V AC or 70 V DC)

may still be present.

¾

Before touching live parts, check

for the presence of dangerous

voltages by means of direct,

double-pole contact measurement

of the alternating current area.

Cable break detector

The cable break detector is for the non-contact

detection of cable breaks in unexposed, live cables.

■

Set the selector switch to

CABLE BREAK DETECT

.

3

If the sensor at the top end of the multimeter is

moved along a live cable (100 - 300 V AC)

starting from the feed-in point, while keeping the

M

 button

[8]

 pressed, the display

[1]

 flashes

and a beep is emitted before the break point.

   DANGER!

The non-contact cable break detection

function is not suitable for the detec

-

tion of dangerous mains voltages.

The non-contact sensor can only detect

voltages created by power sources

with sufficiently strong electric fields

(mains network, > 100 V AC).

■

In weaker electric fields, the device may not

recognise the applied voltage and therefore not

be cable to correctly locate the cable break.

■

If the device does not detect any voltage, this

may be caused, amongst others, by the following

factors:

•  Shielded cables/wires

•  Thickness and type of insulation

•

Distance to the voltage source

DC voltage

Measuring

range

Resolution

Accuracy

200 mV

0.1 mV

± 0.5 % of the mea

-

sured value + 3 digits

± 0.8 % of the mea

-

sured value + 3 digits

2 V

0.001 V

20 V

0.01 V

200 V

0.1 V

600 V

1 V

Input resistance: 10 MΩ.

Max. input voltage: 600 V DC.

Alternating current measurement

■

Set the selector switch

[4]

 to

V~

.

■

Connect the black measuring lead to the

COM

socket

[5]

and the red measuring lead to the

right socket.

■

Connect the measuring leads to the test object.

■

The multimeter automatically searches for the

most favourable measurement range. Read the

measurement result from the display

[1]

.

AC voltage

Measuring

range

Resolution

Accuracy

200 mV

1 mV

± 1.5 % of the mea

-

sured value + 5 digits

2 V

0.001 V

20 V

0.01 V

200 V

0.1 V

600 V

1 V

Input resistance: 10 MΩ.

Max. input voltage: 600 V AC RMS,

frequency range: 40-400 Hz.

■

Before measuring make certain that all other test

leads are removed.

■

The red test lead can be used for single phase

testing by pressing the

M

 button

[8]

.

3

The display

[1]

 flashes and a bleep is heard.
