14

TOPEX.PL

FUNCTION: ALTERNATING CURRENT MEASUREMENT

RANGE

RESOLUTION

ACCURACY

2000μA

1μA

+- (1,2% + 5)

20mA

10μA

+- (1,5% + 5)

200mA

100μA

+- (1,5% + 5)

Overload protection of measurement ranges up to 200mA: quick blow fuse 250mA/250V.

FUNCTION: BATTERY TEST

RANGE

DESCRIPTION

TEST CONDITIONS

1.5V

Display shows battery voltage. It allows to estimate battery level.  Operating current approx. 20mA

9V

1.5V or 9V.

Operating current approx. 5mA

FUNCTION: CONTINUITY TEST

RANGE

DESCRIPTION
If resistance of examined circuit is be smaller than 30Ω a built-in beeper will activate. You will hear
sound signal.

FUNCTION: SEMICONDUCTOR DIODE TEST

RANGE

DESCRIPTION
LCD display shows diode forward voltage.

FUNCTION: RESISTANCE MEASUREMENT

RANGE

RESOLUTION

ACCURACY

200Ω

100mΩ

+- (1,0% + 3)

2000Ω

1Ω

+- (0,8% + 3)

20kΩ

10Ω

+- (0,8% + 3)

200kΩ

100Ω

+- (0,8% + 3)

2000kΩ

1kΩ

+- (0,8% + 3)

20000kΩ

10kΩ

+- (1,2% + 3)

TAKING MEASUREMENTS

DIRECT VOLTAGE MEASUREMENT

Connect red test lead to VΩ terminal, black test lead to COM terminal.

1.

Set the dial function selector to DC voltage  „

2.

„ and correct range corresponding to measured value. If you do

not know range of DC voltage set the selector switch to maximum range and then reduce it gradually for the best
measurement accuracy.
Switch on the multimeter with “Auto Power” button.

3.

Connect or press test probes to measurement spots in the device or circuit. Measured voltage value and its polarity

4.

will be shown on the LCD display.

AC VOLTAGE RMS MEASUREMENT

Connect red test lead to VΩ terminal, black test lead to COM terminal.

1.
