>   DESCRIPTION OF THE MACHINE

(pict.3,4)

①

Handle

②

Pressure control

③

Pressure-gauge

④

High pressure water outlet

⑤

Water inlet + filter

⑥

Power cord

⑦

ON/OFF switch

⑧

Detergent tank

⑨

H.P. nozzle

⑩

Rubber hose fitting

⑪

Lance

⑫

High pressure hose

⑬

Gun trigger lever

⑭

Spray gun

>  WATER SUPPLY

    Water supply connection

WARNING:

 (synbol) machine not suitable

for connection to the potable water mains.

Caution - Danger!

Only clean or filtered water should be used for

intake. The delivery of the water intake tap

should be equal to the double of the maxi-

mum pump range.

-  Minimum delivery rate: 20 l/ min.

-  Maximum intake water temperature: 40°C

-  Max inlet water pressure: 1Mpa
Place the cleaner as close to the water supply

system as possible.

Water supply from the water main

-  (pict.5 pos.

⑤

) Connect a supply hose (not

included) to the water inlet of the unit and to

the water supply (max. pressure 10 bar).

-  (pict.6 pos.

④

) Connect high pressure hose to

the machine connection  and turn on the water

tap.

The cleaner can be connected directly to the

mains drinking water supply hose is fitted

with a backflow preventer valve as per cur-

rent regulations in force.

Make sure that the hose is at least Ø 13 mm and

that it is reinforced.

Failure to comply with the above conditions

causes serious mechanical damage to the

pump and the loss of warranty cover.

>     HIGH PRESSURE HOSE

•

WARNING:

 The high pressure hose is designed

and produced to withstand high pressures. To

avoid damage, it must be handled with special

care.

Misuse may lead to premature breakages or dam-

age and cause the loss of warranty cover. See

illustrations (pict.24). Use the hydrocleaner only

if the hose is completely uncoiled and extended.

>     ELECTRICITY SUPPLY

-  The appliance’s electrical connection must

comply with the IEC 364 standard.

IMPORTANT:

Before connecting the appli-

ance, make sure that the nameplate data are

the same as those of the electrical mains and

that the socket is protected by a differential

security breaker with tripping sensitivity below

0.03 A - 30 ms.

-  If the appliance’s plug is not compatible with

the socket, have the socket replaced with an-

other of suitable type by professionally quali-

fied staff.

-  Never use the appliance in ambient tempera-

tures below 0° C if it is equipped with a PVC (H

VV-F) cable.

Check that the mains voltage is the same as that of

your machine, indicated on the technical data

plate. Your electrical system must be constructed

by qualified technicians capable of working in

accordance with the requirements of the regula-

tions in force (earth connection, fuses, differential

security breaker, etc).

In case of failure to comply with one of the regu-

lations stated above, the manufacturer de-

clines all responsibility for the staff and pro-

vides no warranty.

IMPORTANT: Regarding three-phase motors,

pay attention to the connection of the electric

cable to the plug (see electric diagram).

•

 XY  WARNING:

 Inadequate extension cords

can be dangerous.

•

  XJ WARNING

: If an extension cord is used, the

plug and socket must be of watertight construc-

tion.

Information for supply may also be obtained from

the plug manufacturer.

230-240V

400-415V

3G  2,5 mm

2

4G  2,5 mm

2

max 20 m

max 30 m

EN

19
