5

English

PREPARATION BEFORE OPERATION

Handles must be placed on the frame in the following way: loosen the screw

and turn the handle by 90 degrees to place it in the horizontal position.

Tighten the screw.

CONNECTION OF THE AUGER TO THE REDUCTION GEAR

Combine drive shaft and shank end. Insert the shaft into the shank end. Fix

the connection with the help of pin. Use the adapter if you want to set the

auger bit with another type or diameter of the attachement.

AUGER CHECKUP

1. Check availability of all parts. This goes especially for the spark plug.

2. Check the air intake and outlet for clogging.

3. The auger uses an air-cooled engine. If the air passage is blocked, the

engine may overheat.

4. Check the air filter for dirt. A dirty air cleaner will cause the auger to burn

excess fuel.

THE LEVEL OF OIL IN THE ENGINE

Caution

: Oil is a major factor affecting performance and service life. Use

detergent oil. It’s not recommended to use vegetable-based fluid. Check

the engine oil level with the engine stopped and in a level position.

Note

: SAE 10W-30 is recommended for general use. Use oil SAE Synthetic

5W-30 when the average temperature in your area is within the recom-

mended range.

Check the engine with the engine stopped and in a level position.

1.Remove the oil filler cap/dipstick and wipe it clean.

2. Insert the oil filler cap/dipstick into the oil filler neck as shown, but do

not screw it in, then remove it to check the oil level.

3. Add the oil. If the oil level is near or below the lower limit mark on the

dipstick.

NOTE

:

SHIP AND STORE THE GROUND DRILL ONLY IN THE UPPER PO-

SITION OF THE STARTER. OTHERWISE THE OIL FROM THE CRANK CASE

CAN GET INTO THE AIR FILTER, CARBURETOR AND CYLINDER. THE

TRANSPORTATION IN THE PACKAGE WITH OPERATING FLUIDS (OIL,

PETROL) IS FORBIDDEN!
