RU 14

UTV 82

RU 15

IMPORTANT

: After this, the unit will scan the remote sensors (Ch 1 to Ch 3) in the

Temperature Window. There is no immediate need to press any button during this

process.

After this, the unit will start to scan the DCF77 time transmitter in the Clock Window.

Thereby, the default time the unit has started with at the beginning is 12:00. Here too,

there is no immediate need to press any button during this process.

Recommendation: Allow the unit to receive the sensors and the time without touching

ANY button for about 6-8 minutes during the main unit initial set up. This will give the

unit time to synchronize with remotes, stabilize pressure readings and settle with default

settings.

• WEATHER FORECAST

This unit is capable of detecting the atmospheric pressure changes. Based on collected

weather data, it forecasts the weather for the next 12 to 24 hours.

NOTE:

 The weather forecast accuracy is approximately 70%. The wetherstation shows

the forecasted (predicted), not the current conditions. The SUNNY icon indicates

clear weather, even when displayed during the night-time.

• TEMPERATURE WINDOW

The main unit supports up to 3 remote sensors, each corresponding to a separate channel

of the temperature display. The temperature can be displayed in

Celsius (ºC) or Fahrenheit (ºF).

A temperature alert function is available for all channels. It can be programmed to sound

once one of the remote temperatures exceeds or falls below the pre-set upper and lower

limits.

OPERATION OF THE TEMPERATURE WINDOW

For all operations described in Chapter 4.2, press

UP

 (▲) or

DOWN

 (▼) until the

icon, to the left of the indoor temperature value, begins to flash.

FORCED SEARCH FOR REMOTE SENSORS

Select the TEMPERATURE window.

The main unit can be manually activated to search for the signal from the selected remote

sensor by pressing and holding the

DOWN

 (▼) button for 3 seconds.

The wave icon above the current channel icon shows the connection status of the

corresponding remote sensor:

With this search procedure the device searches the same sensor that was already

previously logged in. If you replace the batteries in the sensor, the sensor gives itself a new

Symbols on the

display

Sunny

Slightly cloudy

Clouded

Strong rain

Heavy snow

Snow

Rainy

Forecast

Symbols on the

display

Forecast

Icon

Status

Searching for the signals from the remote sensor

Corresponding remote sensor signal received

successfully

No signals received for over 1 hour
