- 51 -

BIOS Setup

  When a Cable Problem Occurs...



If a cable problem occurs on a specified pair of wires, the

Status

 field will show

Short

 and then length

shown will be the approximate distance to the fault or short.



Example:

Part1-2 Status = Short / Length  =  2m



Explanation: A fault or short might occur at about 2m on Part 1-2.



Note: Part 4-5 and Part 7-8 are not used in a 10/100 Mbps environment, so their

Status

 fields will show

Open

, and the length shown is the approximate length of the attached LAN cable.

  Onboard LAN Boot ROM



Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.



(Default: Disabled)

  R_USB30 Controller (Etron EJ168 USB Controller, USB 3.0/2.0 ports on the back panel)





Enables or disables the back panel Etron EJ168 USB controller. (Default: Enabled)

  R_USB30 Turbo (Etron EJ168 USB Controller, USB 3.0/2.0 ports on the back panel)





Enables or disables the Turbo USB mode for the Etron EJ168 USB controller. The actual





performance may vary depending on the number of devices being installed. (Default: Disabled)

  F_USB30 Controller (Etron EJ168 USB Controller, USB 3.0/2.0 ports routed to the on-

  board F_USB30 header)


Enables or disables the front panel Etron EJ168 USB controller. (Default: Enabled)

  GSATA3 Controller (Marvell 88SE9172 Chip, GSATA3_6 and GSATA3_7 connectors)



Enables or disables the SATA controller integrated in the Marvell 88SE9172 chip. (Default: Enabled)

  GSATA3 Ctrl Mode (Marvell 88SE9172 Chip, GSATA3_6 and GSATA3_7 connectors)



Enables or disables RAID for the SATA controller integrated in the Marvell 88SE9172 chip or configures

the SATA controller to AHCI mode.



IDE

Configures the SATA controller to IDE mode. (Default)



AHCI

 Configures the SATA controller to AHCI mode. Advanced Host Controller Interface (AHCI)
is an interface specification that allows the storage driver to enable advanced Serial ATA

features such as Native Command Queuing and hot plug.



RAID

Enables RAID for the SATA controllers.

  Onboard Serial Port 1



Enables or disables the serial port and specifies its base I/O address and corresponding interrupt.

Options are: Auto, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled.
