BIOS Setup
Current Voltage(V) Vcore/DDR15V/+12V/Vtt
Displays the current system voltages.
Current System/CPU Temperature
Displays current system/CPU temperature.
Current CPU/SYSTEM FAN Speed (RPM)
Displays current CPU/system fan speed.
CPU Smart FAN Control
Allows you to determine whether to enable the CPU fan speed control function and adjust the fan speed.
Normal
Allows the CPU fan to run at different speeds according to the CPU temperature. You can
adjust the fan speed with EasyTune based on your system requirements. (Default)
Silent
Allows the CPU fan to run at slow speeds.
Manual Allows you to control the CPU fan speed under the
Slope PWM
item.
Disabled Allows the CPU fan to run at full speeds.
Slope PWM
Allows you to control the CPU fan speed. This item is configurable only when
CPU Smart FAN Control
is set to
Manual
. Options are: 0.75 PWM value /
o
C ~ 2.50 PWM value /
o
C.
CPU Smart FAN Mode
Specifies how to control CPU fan speed. This item is configurable only when
CPU Smart FAN Control
is enabled.
Auto
Lets the BIOS automatically detect the type of CPU fan installed and sets the optimal
CPU fan control mode. (Default)
Voltage Sets Voltage mode for a 3-pin CPU fan.
PWM
Sets PWM mode for a 4-pin CPU fan.
Note: The
Voltage
mode can be set for a 3-pin CPU fan or a 4-pin CPU fan. However, for a 4-pin CPU
fan that is not designed following Intel PWM fan specifications, selecting
PWM
mode may not effectively
reduce the fan speed.
2-8 PC Health Status
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
PC Health Status
Vcore
1.172V
DDR15V
1.516V
+12V
11.779V
Vtt
1.076V
Current System Temperature
30
o
C
Current CPU Temperature
47
o
C
Current CPU FAN Speed
3375 RPM
Current SYSTEM FAN Speed
0 RPM
CPU Smart FAN Control
[Normal]
x Slope PWM
1.75 PWM value /
o
C
CPU Smart FAN Mode
[Auto]
hi
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
