Unique Features

- 64 -

4-3  EasyTune 6

GIGABYTE's  EasyTune  6  is  a  simple  and  easy-to-use  interface  that  allows  users  to  fine-tune  their  system

settings  or  do  overclock/overvoltage  in  Windows  environment.  The  user-friendly  EasyTune  6  interface  also

includes tabbed pages for CPU and memory information, letting users read their system-related information

without the need to install additional software.

The EasyTune 6 Interface

Tabs Information

Available  functions  in  EasyTune  6  may  differ  by  motherboard  model.  Grayed-out  area(s)  indicates  that  the  item  is

not configurable or the function is not supported.

(Note)   Due to the hardware limitation, you must install a DDR3 1066 MHz memory module(s) (or above) to enable

support for Quick Boost.

Incorrectly  doing  overclock/overvoltage  may  result  in  damage  to  the  hardware  components  such  as  CPU, chipset,
and memory and reduce the useful life of these components. Before you do the overclock/overvoltage, make sure

that you fully know each function of EasyTune 6, or system instability or other unexpected results may occur.

Tab

Function

The CPU tab provides information on the installed CPU and motherboard.
The  Memory  tab  provides  information  on  the  installed  memory  module(s).  You  can  select  memory

module on a specific slot to see its information.

The

Tuner

 tab allows you to change system clock settings and voltages.

•

Quick Boost mode

 provides you with 3 levels of CPU frequency/base clock to choose to achieve

desired system performance.

(Note)

After making changes in

Quick Boost mode

 or clicking

Default

 to restore to default values, be

sure to restart your system for these changes to take effect.

Easy mode

•

 allows you to adjust the CPU base clock only.

•

Advanced mode

 allows you to individually change system clock settings and voltages settings us-

ing the sliders.

Save

•

 allows you to save the current settings to a new profile (.txt file).

Load

•

 allows you to load previous settings from a profile.

After  making  changes  in

Easy  mode/Advanced  mode

,  be  sure  to  click

Set

  for  these  changes  to

take effect or click

Default

 to restore to default values.

The Graphics tab allows you to change the core clock and memory clock for your ATI or NVIDIA
The  Smart  tab  allows  you  to  specify  a  Smart  Fan  mode.  Smart  Fan Advanced  mode  allows  the  CPU

fan speed to be changed linearly based on the CPU temperature thresholds you set.
The  HW  Monitor  tab  allows  you  to  monitor  hardware  temperature,  voltage  and  fan  speed  and  set

temperature/fan  speed  alarm.  You  can  choose  the  alert  sound  from  the  buzzer  or  use  your  own

sound file (.wav file).
