GA-8S648FX-775(-C) Motherboard

- 62 -

English

Please follow the steps below to construct a complete RAID array:
1) Have ready your hard drives for RAID construction.

Note: To achieve best performance, it is recommended that the hard drives used are of similar
make and storage capacity.

2) Please attach the hard drive connectors to their appropriate location on the motherboard ie. IDE,

SCSI, or SATA.

3) Enter the motherboard BIOS and locate RAID setup (Please refer to the section on Integrated

Peripherals).

4) Enter RAID setup in the BIOS and select the RAID type (For instance, press Ctrl-S to enter SiS

RAID BIOS).

5) Complete driver installation.
6) Complete RAID utility installation.
More information is provided on the steps below.

Configuring the SiS RAID BIOS

The SiS RAID BIOS Setting Utility lets you choose the RAID array type and which hard drives you want to
make part of the array.
Entering the RAID BIOS Setup
After rebooting your computer, wait until you see the RAID software prompting you to press Ctrl-S (Figure 1).
The RAID prompt appears as part of the system POST and boot process prior to loading the OS. You have
a few seconds to press Ctrl-S before the window disappears.

Press Ctrl-S. The SiS RAID BIOS Setting Utility - Disk Status window appears (refer to Figure 2).
To create RAID, press <R> to enter the RAID Setup utility.

Silicon Integrated Systems Corp. RAID BIOS Setting Utility v1.05_964
(c) 2003-2005 Silicon Integrated Systems Corp. All Rights Reserved.

Press <Ctrl><S> to enter Setup Menu or <ESC> to skip waiting.

Primary Master:

ST3120026AS

111GB

UDMA6

Secondary Master:

ST3120026AS

111GB

UDMA6

¹Ï5

SiS RAID BIOS Setting Utility

Disk Status

* Current Created Raid *

[R] : Enter Raid setup utility

[Q] : Exit current menu

Location Model

Capacity

Mode

RAID Type

Disk 1

ST3120026AS

111GB

UDMA 6

Single

Disk 2

ST3120026AS

111GB

UDMA 6

Single

Figure 1

Figure 2
