Introduction

English

- 5 -

Form Factor

y

24.3cm x 24.3cm Micro ATX size form factor, 4 layers PCB

C P U

y

Socket 478  for Intel

®

 Micro FC-PGA2 Pentium

®

 4 processor

y

Support Intel

®

  Pentium

®

 4 (Northwood, Prescott) processor

y

Support Intel

®

 Pentium

®

 4 Processor with HT Technology *

y

Intel

®

 Pentium

®

 4 800/533/400MHz FSB

y

2nd cache depends on CPU

Chipset

y

Intel

®

 Chipset 865G HOST/AGP/Controller

y

Intel

®

 ICH5 I/O Controller Hub

Memory

y

4 184-pin DDR DIMM sockets

y

Supports Dual Channel DDR400/DDR333/DDR266 DIMM

y

Supports 128MB/256MB/512MB/1GB unbuffered DRAM

y

Supports up to 4GB DRAM (Max)

 (Note 1)

y

Supports only DDR DIMM

I/O Control

y

ITE8712F

Slots

y

1 AGP slot 4X/8X (1.5V) device support

y

3 PCI slot supports 33MHz & PCI 2.3 compliant

On-Board IDE

y

2 IDE controllers provides IDE HDD/CD-ROM (IDE1, IDE2) with
PIO, Bus Master (Ultra DMA33/ATA66/ATA100) operation modes

y

Can connect up to 4 IDE devices

Serial ATA

y

2 Serial ATA connectors in 150 MB/s operation mode

y

Controlled by ICH5

On-Board Peripherals

y

1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M
and 2.88M bytes

y

1 Parallel port supports Normal/EPP/ECP mode

y

1 Serial port (COMA), 1 VGA port, COMB on board

y

8 USB 2.0/1.1 ports (4 x Rear, 4 x Front by cable)

y

1 IrDA connector for IR/CIR

y

1 Front Audio connector

Chapter 1  Introduction

to be continued......

Features Summary

Due to chipset (Intel 865G) architecture limitation, DDR 400 memory module is only supported
when using FSB 800 Pentium 4 processor. A FSB 533 Pentium 4 processor will support
DDR333 and DDR266 memory module. A FSB 400 Pentium 4 processor will only support
DDR 266 memory module.

(Note 1) Due to standard PC architecture, a certain amount of memory is reserved for system usage

and therefore the actual memory size is less than the stated amount. For example, 4 GB of
memory size will instead be shown as 3.xxGB memory during system startup.
