GA-73UM-S2H Motherboard
- 72 -
B.
Configuring SATA controller mode in BIOS Setup
Make sure to configure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test).
Under
Integrated Peripherals
, ensure
NV Serial-ATA Controller
is enabled (Figure 1). Then, go to
the
SATA-II RAID Config
submenu (Figure 2).
Figure 1
The BIOS Setup menus described in this section may differ from the exact settings for your
motherboard. The actual BIOS Setup menu options you will see shall depend on the motherboard
you have and the BIOS version.
Step 2:
Save changes and exit BIOS Setup.
To create a RAID array, set
Onchip SATA Mode
to
RAID
(or set to
IDE
or
AHCI
for non-RAID
configuration). Then, enable RAID functionality for the SATA connectors with hard drives that you want
to use for RAID. For example,
SATA-II Pri-Master RAID
is for the SATAII0 connector and
SATA-II Pri-
Slave RAID
for the SATAII1 connector. (Figure 2). To create a RAID array on hard drive connected to
the eSATA 3Gb/s port on the back panel, set
SATA-II Sec-Slave RAID
to
Enabled
.
Figure 2
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
Integrated Peripherals
On-Chip IDE Channel0
[Enabled]
IDE Prefetch Mode
[Enabled]
NV Serial-ATA Controller
[All Enabled]
`
SATA-II RAID Config
[Press Enter]
On-Chip MAC Lan
[Auto]
Onboard LAN Boot ROM
[Disabled]
Onboard Audio Function
[Auto]
On-Chip USB
[V1.1+V2.0]
USB Memory Type
[SHADOW]
USB Keyboard Support
[Disabled]
USB Mouse Support
[Disabled]
Onboard 1394
[Enabled]
`
SMART LAN
[Press Enter]
Legacy USB storage detect
[Enabled]
Onboard Serial Port 1
[3F8/IRQ4]
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x ECP Mode Use DMA
3
KLJI
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
`
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
SATA-II RAID Config
Item Help
Menu Level
``
Onchip SATA Mode
[RAID]
SATA-II Pri-Master RAID
[Enabled]
SATA-II Pri-Slave RAID
[Enabled]
SATA-II Sec-Master RAID
[Disabled]
SATA-II Sec-Slave RAID
[Disabled]
KLJI
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
