GA-73UM-S2H Motherboard
- 42 -
Onchip SATA Mode
Enables or disables RAID for the SATA controller integrated in the nVIDIA
®
GeForce 7150/nForce
630i chipset or configures the SATA controller to AHCI mode.
IDE
Disables RAID for the SATA controller and configures the SATA controller to
PATA mode. (Default)
AHCI
Configures the SATA controller to AHCI mode. Advanced Host Controller
Interface (AHCI) is an interface specification that allows the storage driver to
enable advanced Serial ATA features such as Native Command Queuing and
hot plug.
RAID
Enables RAID for the SATA controller.
SATA-II Pri-Master RAID
Enables or disables RAID for the first SATA 3Gb/s connector (SATAII0). This item is configurable
only if the
Onchip SATA Mode
item is set to
RAID
. (Default: Enabled)
SATA-II Pri-Slave RAID
Enables or disables RAID for the second SATA 3Gb/s connector (SATAII1). This item is configurable
only if the
Onchip SATA Mode
item is set to
RAID
. (Default: Enabled)
SATA-II Sec-Master RAID
Enables or disables RAID for the third SATA 3Gb/s connector (SATAII2). This item is configurable
only if the
Onchip SATA Mode
item is set to
RAID
. (Default: Enabled)
SATA-II Sec-Slave RAID
Enables or disables RAID for the eSATA 3Gb/s port (ESATA) on the back panel. This item is
configurable only if the
Onchip SATA Mode
item is set to
RAID
. (Default: Enabled)
On-Chip MAC Lan
Enables or disables the onboard LAN function. (Default: Auto)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item
to
Disabled
.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
Onboard Audio Function
Enables or disables the onboard audio function. (Default: Auto)
If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item
to
Disabled
.
On-Chip USB
Configures the integrated USB controller.
V1.1+V2.0
Enables the integrated USB 1.1 and USB 2.0 controllers. (Default)
V1.1
Enables only the integrated USB 1.1 controller.
Disabled
Disables the integrated USB 1.1 and USB 2.0 controllers.
USB Memory Type
Specifies the type of memory allocated for USB devices. Options are: SHADOW (default), Base
Memory (640K).
USB Keyboard Support
Allows USB keyboard to be used in MS-DOS. (Default: Disabled)
USB Mouse Support
Allows USB mouse to be used in MS-DOS. (Default: Disabled)
Onboard 1394
Enables or disables the onboard IEEE 1394 function. (Default: Enabled)
