- 21 -
BIOS Setup
English
Chapter 2 BIOS Setup
CONTROL KEYS
< > < ><
>< >
Move to select item
<Enter>
Select Item
<Esc>
Main Menu - Quit and not save changes into CMOS Status Page Setup Menu
and Option Page Setup Menu - Exit current page and return to Main Menu
<+/PgUp>
Increa se the num eric value or make c hanges
<-/PgDn>
Decre ase the numeric value or make ch anges
<F1>
General help, only for Status Page Setup Menu and Option Page Setup Menu
<F2>
Item Help
<F5>
Restore the previous CMOS value from CMOS, only for Option Page Setup Menu
<F6>
Load the file-safe default CMOS value from BIOS default table
<F7>
Load the Optimized Defaults
<F8>
Q-Flash utility
<F9>
System Information
<F10>
Save all the C MOS chang es, only for Main Menu
Chapter 2 provides an overview of the BIOS Setup Program, which allows users to modify the basic
system configurations. This type of information is stored in battery-backed CMOS RAM so that it retains
the Setup information when the power is turned off.
ENTERING BIOS Setup
Turning on the computer and pressing <Del> immediately allow you to enter BIOS Setup. If you need
more advanced BIOS settings, please press
Ctrl
and
F1
keys on the BIOS main screen to access the
the advanced BIOS settings.
Main Menu
The on-line description of the highlighted setup function is displayed at the bottom of the screen.
Status Page Setup Menu / Option Page Setup Menu
Press F1 to pop up a small help window that describes the appropriate keys to use and the possible
selections for the highlighted item. To exit the Help Window, press <Esc>.
The Main Menu (For example: BIOS Ver. : F8c)
Once you enter Award BIOS CMOS Setup Utility, the Main Menu (as figure below) will appear on the
sc reen . Th e Ma in Menu all ows you to sele ct f rom eig ht s etup fun cti ons and two exi t ch oice s. U se
arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.
CMOS Setup Util ity-Copyright (C) 1984-2004 Award Software
}
Standa rd CMOS Fe atures
}
Advanc ed BIOS Fe atures
}
Integrated Peripherals
}
Power Management Setup
}
PnP/PCI Con figurations
}
PC H ealth St atus
}
MB Intel ligent Tweaker (M.I.T.)
Top Perf ormance
Load F ail-Safe De faults
Load O ptimized De faults
Set Su pervisor Pa ssword
Set User Password
Save & Exit S etup
Exit Witho ut Saving
ESC: Quit
higf
: Selec t Item
F8: Q-Flash
F10: S ave & Exit Setup
Time, Date, Har d Disk Type...
