4 | Chapter 1: Introduction

1�3

Specifications

Specifications

CPU Support

Support for 10th/ 11th Generation Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Pentium® processors/
Intel® Celeron® processors in the LGA1200 package
* Please refer to www.biostar.com.tw for CPU support list.

Chipset

Intel® B560

Memory

Supports Dual Channel DDR4 3333+(OC)/ 3200/ 2933/ 2666/ 2400/ 2133/ 1866
2x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.

Storage

-- Total supports 1x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s)
1x M.2 (M Key) Socket:
Supports M.2 Type 2242/ 2260/ 2280 SSD module.
Supports PCI-E 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA III (6Gb/s) SSD
* When using SATA SSD module on M.2 slot (M2_PCIEG3_32G_SATA_1), the SATA_1 connector will
be disabled.

LAN

intel® I219V
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

Audio Codec

Realtek ALC897
7.1 Channels, High Definition Audio

USB

4x USB 3.2(Gen1) port (2 on rear I/Os and 2 via internal headers)
8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)

Expansion Slots

1x PCIe 3.0 x1 Slot
1x PCIe 3.0/ 4.0 x16 Slot (x16 mode)
* The PCIe 4.0 only depends on Rocket Lake CPUs.

Rear I/Os

2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI Port
1x VGA Port
2x USB 3.2 (Gen1) Port
4x USB 2.0 Port
1x LAN port
3x Audio Jack

Internal I/Os

4x SATA III Connector (6Gb/s)
1x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel® CNVi
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
* M.2 (E key) Wi-Fi card is not provided

Form Factor

uATX Form Factor, 208 mm x 236 mm

OS Support

Windows 10(64bit) / Windows 11(64bit)
* Biostar reserves the right to add or remove support for any OS with or without notice.
