Operation

9

9

Operation

Radio operations

In Radio mode press the BND button to
select a radio band: FM1 => FM2 => FM3.

Band select

• Shortly press        or       button. AUTO

will be displayed on the screen. The radio
will automatically search for the previous or
next frequency with a strong and clear
signal.

• Press and hold

       or

will go to the manual tuning mode, MANUAL
will be displayed. Press       /       buttons
repeatedly to adjust the needed frequency
manually. If both buttons have not been
pressed for several seconds, the device will
return to AUTO mode.

Automatic / manual tuning

Storing and recalling stations

Auto storing
Press and hold the

BND

 button for

several seconds to automatically find and
store the 6 strongest stations in the
current band corresponding to the preset
number button. Press either of the 6
number buttons to recall a stored station.

Manual storing and recalling
• Tune to a station as described above

in the Automatic / manual tuning section.

• Press and hold one of the 1- 6 preset

button for 2 seconds until LCD shows the
corresponding number, which indicates
that station is stored on this number.

• Press 1- 6 preset buttons to listen to

stored stations.

Note: the unit can stored up to 6 stations
for each of the three bands.

USB/SD operations

Carefully insert an SD memory card into

the card slot on the front panel. Unit starts
playback automatically. To disconnect the
memory card, press it until a click, and then
carefully pull it out from the slot.

SD card slot

Carefully connect a USB driver to the

USB port on the front panel. Unit starts
playback automatically.

USB port

USB format supports 2.0. Capacity: up to

32 GB. SD cards capacity: up to 32 GB.
Supported file systems are FAT/FAT32.
Note: Because of the great variety of
products with SD-card slots and their
sometimes quite manufacturer-specific
functions the producer can neither
guarantee that all devices will be
recognized nor that all operating options
that are possible in theory will actually work.
Before disconnecting a storage, switch the
unit to another mode.

For correct and satisfactory operation,

licensed SD/MMC memory cards of well-
known brands should
be used with this unit. Avoid using memory
cards of unknown brands. Some models of
USB devices cannot be supported by this
unit due to incompatibility.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary
power supply. Failure to use supplementary
power for connected USB drives with power
consumption exceeding this value
as well as defective USB drives may cause
mechanical or thermal changes of elements
of the unit as well as failure of internal
elements of USB port. Such damages are
not warranty cases.

USB/SD notes
