JVC KD-G722 - Инструкция по эксплуатации - Страница 29

ENGLISH

29

Specifications

  AUDIO AMPLIFIER SECTION

Maximum Power Output:


Front:  50 W per channel

Rear:  50 W per channel

Continuous Power Output (RMS):


Front:  19 W per channel into 4

Ω

, 40 Hz

to 20 000 Hz at no more than 0.8%
total harmonic distortion.

Rear:  19 W per channel into 4

Ω

, 40 Hz

to 20 000 Hz at no more than 0.8%
total harmonic distortion.

Load Impedance: 4

Ω

 (4

Ω

 to 8

Ω

 allowance)

Tone Control Range:


Bass:  ±10 dB at 100 Hz

Treble:  ±10 dB at 10 kHz

Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance:


2.5 V/20 k

Ω

 load (full scale)

Output Impedance: 1 k

Ω

Subwoofer-Out Level/Impedance:


2.0 V/20 k

Ω

 load (full scale)

Other Terminals:


CD changer, Steering wheel remote input

  TUNER SECTION

Frequency Range:


FM:

87.5 MHz to 108.0 MHz

AM:

(MW)  522 kHz to 1 620 kHz

(LW)  144 kHz to 279 kHz

[FM Tuner]

Usable Sensitivity: 11.3 dBf (1.0 μV/75

Ω

)

50 dB Quieting Sensitivity:


16.3 dBf (1.8 μV/75

Ω

)

Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB

[MW Tuner]

Sensitivity: 20 μV
Selectivity: 35 dB

[LW Tuner]

Sensitivity: 50 μV

  CD PLAYER/USB MEMORY SECTION

Type: Compact disc player
Signal Detection System: Non-contact optical

pickup (semiconductor laser)

Number of Channels:  2 channels (stereo)
Frequency Response:  5 Hz to 20 000 Hz
Dynamic Range:

96 dB

Signal-to-Noise Ratio:  98 dB
Wow and Flutter: Less than measurable limit
MP3 Decoding Format:


MPEG1/2 Audio Layer 3

Max. Bit Rate: 320 kbps

WMA (Windows Media

®

 Audio) Decoding

Format:


Max. Bit Rate: 192 kbps

Playable USB memory:


Format: FAT 12/16/32

Storage: Less than 4 GB (1 partition type)

Playable Audio Format: MP3/WMA

Max. Current: Less than 500 mA

  GENERAL

Power Requirement:


Operating Voltage:

DC 14.4 V (11 V to 16 V allowance)

Grounding System: Negative ground
Allowable Operating Temperature:


0°C to +40°C

Dimensions (W × H × D):


Installation Size (approx.):

182 mm × 52 mm × 152 mm

Panel Size (approx.):

188 mm × 58 mm × 11 mm

Mass (approx.):


 1.4 kg (excluding accessories)

Design and specifications are subject to change
without notice.

•  Microsoft and Windows Media are either

registered trademarks or trademarks of
Microsoft Corporation in the United States
and/or other countries.

•  iPod is a trademark of Apple Computer, Inc.,

registered in the U.S. and other countries.
