JVC KD-BT22 - Инструкция по эксплуатации - Страница 44

ENGLISH

44

AUDIO AMPLIFIER SECTION

Maximum Power Output:

Front/Rear:

50 W per channel

Continuous Power Output
(RMS):

Front/Rear:

19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at
no more than 0.8% total harmonic distortion

Load Impedance:

4 Ω (4 Ω to 8 Ω allowance)

Equalizer Control Range:

Frequency:

Band 1: 68 Hz, 100 Hz, 150 Hz
Band 2: 210 Hz, 320 Hz, 460 Hz
Band 3: 680 Hz, 1 kHz, 1.5 kHz
Band 4: 2.1 kHz, 3.2 kHz, 4.6 kHz
Band 5: 6.8 kHz, 10 kHz, 15 kHz

Level:

±12 dB

Q (Q-slope):

Q0.7 to Q2.0

Frequency Response:

40  Hz to 20 000 Hz

Signal to Noise Ratio:

70 dB

Line-Out Level/Impedance:

2.5 V/20 kΩ load (full scale)

Output Impedance:

1 kΩ

Subwoofer-Out Level/Impedance:

4.0 V /20 kΩ load (full scale)

Other Terminal:

AUX (auxiliary) input jack, USB cable, Aerial
input

TUNER SECTION

Frequency Range:

FM1/FM2:

87.5 MHz to 108.0 MHz

FM3:

65.00 MHz to 74.00 MHz

AM:

(MW) 522 kHz to 1 620 kHz

(LW) 144 kHz to 279 kHz

FM Tuner:

Usable Sensitivity:

11.3 dBf (1.0 μV/75 Ω)

50 dB Quieting Sensitivity:

16.3 dBf (1.8 μV/75 Ω)

Alternate Channel Selectivity
(400 kHz):

65 dB

Frequency Response:

40 Hz to 15 000 Hz

Stereo Separation:

30 dB

MW Tuner:

Sensitivity/Selectivity:

20 μV/35 dB

LW Tuner:

Sensitivity:

50 μV

Specifications
