ENGLISH

○ ○ ○ ○ ○ ○ ○ ○ ○

Adjusting AV OUTPUT volume

Select an appropriate volume level for the
component connected to the AV OUTPUT
jacks on the hideaway unit.
• This functions without respect to the Dual

Mode setting.

1

2

3

4

Adjust the AV output volume.

When using the remote controller:

• For Dual Mode operations...

– When controlling the monitor connected

to the AV OUTPUT jacks, aim the
remote controller at the remote sensor
on the main unit.

– When controlling the monitor inserted

into the cradle, aim the remote controller
at the remote sensor on the cradle.

To activate Dual Mode

Each time you press and hold the button,
Dual Mode turns on and off.
• When Dual Mode is turned on, the source

selection screen appears on the monitor
(see page 38).

To operate the subsidiary source
1

2 Press the source buttons, then the

source operation buttons.

To operate the main source
1

2 Press the source buttons, then the

source operation buttons.

ZOOM

DUAL

Hold

MAIN

SUB

AVOUT VOL

On the remote controller

then

MAIN

SUB

MAIN

SUB

*

2

*

1

*

1

*

1

It does not appear for some sources.

*

2

It will be shaded when not available.

While Dual Mode is in use...
• The playback source does not change to

“DISC” though you insert a disc. “DUAL”
flashes on the display of the main unit.

• You can only adjust the volume level for

the subsidiary source (the other sound
adjustments cannot be used for the
subsidiary source).
