10

Operation

  If turn off the power, all the settings

of each mode will be saved. If turn off the
ACC power, all the settings will be clear and
become factory default setting. If you don’t
adjust setting within several seconds after
selecting the desired setting item, the unit will
automatically return to the current mode.

  If Flat, Classic, Pop or Rock equalizer

mode is selected, treble and bass are not
adjustable. For operation with Beep and
Loudness see below System Setup paragraph.

System setup

Press MENU button on the panel or SETUP

button on the RC to enter Setting Menu. Press
UP/DOWN cursor buttons on the RC or rotate
VOLUME knob on the panel to select a menu
page. Press ENTER button or RIGHT cursor
button on the RC or press OK button on the
panel to enter the page. Press UP/DOWN cursor
buttons on the RC or rotate VOLUME knob on
the panel to select an item, then press ENTER
button on the RC or OK button on the panel to
adjust the setting.

SOUND page
•  EQ: Select Flat, Classic, Pop, Rock or

User equalizer mode.

•  Bass: Adjust the low-frequency level.
•  Treble: Adjust the hogh-frequency level.
•  Balance: Adjust the balance between left

and right channels.

•  Fader: Adjust the balance between front

and left channels.

•  Volume: Adjust the sound volume level.
•  Beep: Select ALL (beep is heard at any

button pressing), 2ND (beep is heard when a
button is pressed and held) or OFF (no beep).

•  Loudness: Selecting loudness ON will

emphasize the low frequency output.

DISPLAY page
•  Screen: Select 16:9, 4:3 or FULL screen

modes.

•  Backlight: select LOW, MID or HIGH

display backlight level.

RADIO page

General operations

Reset the unit

Operating the unit for the first time or after

replacing the car battery, you must reset the
unit. Press RESET button (hole) with a pointed
object (such as a ballpoint pen) to set the unit
to initial state.

  When some errors occur, you can also

press RESET button to resume to normal,
and it will erase the clock setting and some
memorized functions.

Turning on/off

Press any button on the panel or the RC

(except OPEN button) to turn on the unit. Press
and hold PWR/MUTE button on the panel or
press POWER button on the RC to turn off the
unit.

Volume control

Rotate VOLUME regulator or press VOL+/

VOL- buttons on the RC to adjust the volume
level.

Mute function

Press PWR/MUTE button on the panel or

MUTE button on the RC to turn the sound off.
“MUTE” will be displayed. Press this button
again or adjust the volume to turn the sound on.

Setting the sound characteristics

Press SEL button on the RC to call setting

menu consisting of following items: EQ =>
BASS => TREBLE => BALANCE => FADER
=> VOLUME => BEEP => LOUDNESS. Press
UP/DOWN cursor buttons on the RC or rotate
VOLUME knob on the panel to select the audio
setting item. Press ENTER button or RIGHT
cursor button on the RC or OK button on the
panel to enter the selected item.

Press LEFT/RIGHT buttons on the RC or

rotate VOLUME knob on the panel to adjust the
audio setting. Press SEL button on the RC again
to save the setting and return to current mode.
