Operation

Operation

General operations

Turning on/off

Press PWR/MUTE button to turn on the unit.

Press and hold PWR/MUTE button to switch
the unit off.

  After the unit is off, the volume level

and radio current settings will be memorized,
and when you turn the unit on it will resume
the stored status you previously set. To protect
your ear from too loud sound, the unit volume
level will turn to 20 automatically when you
turn the unit on if currect volume level setting is
above 20 when your turn the unit off.

Volume control

Rotate VOLUME knob to adjust the volume

level.

Mute function

Press PWR/MUTE button to turn the sound

off. Press it again to turn the sound on.

Audio parameter setting

Press repeatedly SEL button to select the

audio settings: BAS (Bass) => TRE (Treble)
=> BAL (Balance) => FAD (Fader). Rotate
VOLUME knob to adjust each setting.

  If the unit is turned off, all the settings of

each mode will be saved. If cutting off battery
power or resetting the unit, all the settings
will return to factory default settings. If you
don’t adjust the setting within several seconds
after selecting the desired setting, the unit will
automatically return to the current mode being
displayed.

Setting other features

Press and hold SEL button on the panel,

and then shortly press this button repeatedly to
select a setting. Rotate VOLUME knob on the
panel to adjust each setting.

INVOL: Set default volume level when the

unit is turned on.

ADJ: you can set the clock. Rotate VOLUME

knob clockwise to set minutes; rotate VOLUME

knob counterclockwise to set hours.

24 HOUR: choose 24 hour clock display

mode or 12 hour clock display mode.

LOUD ON/OFF: Enable LOUD ON (Default

is LOUD OFF).

BEEP ON/OFF: if BEEP on, pressing any

key will make a beep sound.

Equalizer (DSP) setting

Press DSP button repeatedly to choose

intended sound effect in the sequence: POP
=> ROCK => CLAS => FLAT => NONE.

Mode setting

Press MODE button to select between unit

operation modes: TUNER => CD => SD =>
USB => AUX.

  CD, SD, USB modes will only show on

the display when a USB device, memory card
or a disc is inserted into the unit.

AUX jack

AUX-in jack is intended for connecting an

external audio or video equipment to amplify
the sound. If connection is made correctly, the
audio signal from the external source will be
translated through the acoustics of the head
unit. This enables to adjust the volume and
quality of the sounding. For example, you can
connect an MP3-player to listen to tracks using
the car acoustic system.

Radio operations

Band selection

Press repeatedly BAND button to select your

desired radio band during RADIO mode: FM1,
FM2, FM3 (OIRT), AM1 (MW1), AM2 (MW2).
In each set of the bands you can store up to 6
preset stations, making total 30 preset memory
stations.

Automatic tuning

To find a station, select a band first, then

press and hold

/

 buttons, the automatic
