Operation

When REG is disabled (off), the receiver

ignores regional variants.

Mono/Stereo control

(

in FM radio mode

)

Press and hold SEL button, then press it

repeatedly until the display shows STEREO
(MONO). Turn VOLUME knob to switch
between ON (stereo reception) or OFF (mono
reception). Improvement of reception of distant
stations can be done by selecting mono mode,
which may cut down some reception noise.

Local radio station search

Press and hold SEL button, then press it

repeatedly until the display shows LOCAL
(DISTANT). When the LOCAL function is on, the
local stations (stations with weak radio signal)
can be played. When the DISTANT function is
on, both local and distant stations (stations with
strong radio signal) can be played.

Setting other features

Press and hold SEL button, then press it

repeatedly until the display shows one of these
settings: TA VOL => EON. Rotate VOLUME
knob to adjust each setting, and press SEL
button to confirm the adjustment.

TA VOL: Adjust the volume for TA

announcement.

EON: Choose EON ON/OFF. The default

setting is ON.

Disc/USB/SD/MMC operations

USB/SD/MMC notes

USB format supports 2.0. Capacity: up to 8

Gb.

For correct and satisfactory operation,

licensed SD/MMC memory cards of famous
brands should be used with this unit. Avoid using
memory cards of unknown brands. Capacity: up
to 8 Gb.

Loading/Ejecting a disc

Open the front panel and insert a disc into

the disc slot with label side up. The disc will be
automatically loaded into the unit. The first file
in the root folder will be played.

Open the front panel and press EJECT

button to eject the disc from the slot. If the disc
is not removed from the slot within several
seconds, it will be automatically loaded into
the slot again. When the disc is ejected and
removed, the unit will automatically switch to
another mode.

Inserting the SD/MMC/USB device

Open the front panel and insert an SD/

MMC memory card into the card slot. Open the
USB slot cover on the front panel and insert a
USB into the USB slot. Then the playing mode
will be changed into MMC/SD or USB mode
automatically. The first card/USB device track
playback will start.

  When SD/MMC card and USB device are

both inserted, the playing mode will be changed
into the mode of the device inserted later.

Stopping playback

The unit will automatically play from the first

sound track recorded on a disc/SD/MMC /USB
device. To ensure good system performance,
wait until the unit finishes reading the disc/
device information before proceeding. To stop
playback, press MODE button and select a
different mode. When you go back to disc/
USB/card playback mode, the playback will
continue from the point it was stopped on.

Play/pause

During playback press MEM/

 button to

pause playback. Press this button again to
resume playback.

Playing the previous/next track

During playback press

 button to play the

previous track. Press

 button to play the

next track.

Fast forward/rewind

Press and hold

/

 buttons to select
