15

General information

The display

shows an

error message

(ERROR 1 – 11)

one time.

Possible disc error.

Reset the unit by pressing RESET hole.

Ensure the disc is inserted correctly into

the slot.

Clean or change the disc.

The display

shows an

error message

(ERROR 1 – 11)

repeatedly.

Unit operation error.

Turn to a service center.

Specifications

General

Power supply

12 V DC

Current consumption

max. 10 A

Maximum power output

4 x 50 W

Fuse

10 A

Dimensions/Net weight

178 x 50 x 175 mm/1.55 kg

Temperature range

-20

0

C - +60

0

C

FM stereo radio

Frequency range

65.0 - 74.0/87.5 - 108.0 MHz

Presettable stations

18

Usable sensitivity

9 uV

MW Section

Frequency range

522 kHz-1620 kHz

Presetable stations

12

Usable sensitivity

30 dB

Disc player

System

Compact disc audio system

Medium support

CD/CD-R/CD-RW, USB/SD/MMC

Format support

CDDA/MP3

Frequency characteristics

20 Hz - 20 kHz

ESP

40 sec. for CD/120 sec. for MP3

Mounting angle

0 - +/-30

0

Line out

Output:

2-channel RCA line out (2V)

Specifications are subject to change without notice. Dimensions are approximate.
