10

Operation

you do not have to retune the stations when
driving between different transmitter coverage
areas. When AF symbol is on, it means RDS
information is received; when AF symbol is
flashing, it means RDS information is not yet
received. If RDS service is not available in your
area, turn off the AF mode.

TA (Travel Announcement) / TP

(Travel Program Identification)

Enable or disable TA mode by pressing and

holding BAND button. Default setting is OFF.

When TA function is activated, it will search

the station with TA information automatically.
If there is no TA information, it will search the
station with TP information automatically, if
there is no TP information either, it will return to
the previous station after searching.

When receiving the station with TP

information but without TA information, TP
icon is on and TA icon keeps blinking; when
receiving the station with TP and TA information,
both TP and TA icons are on. When playing in
other mode and TA information is received, it will
change to the radio mode automatically. After
playing over, it will return to the previous mode.

PTY (Program Type)

(for FM radio)

Press and hold SEL button, then press it

repeatedly to select PTY. Press and hold DISP
to enter PTY program type selection and rotate
VOLUME regulator to select a PTY type. After
selecting the program type you want, press
MEM/

 button to search for corrsponding

program. Press the button again to stop the
PTY search. If PTY code is different or not
available, then display blinks with “PTY NONE”.

REG (Regional) function

Press and hold SEL button, then press it

repeatedly to select REG, then rotate VOLUME
knob to set this function on/off. Default setting
is off for REG.

When REG is enabled (on), the receiver

accepts regional variants of the tuned station
with REG icon turned on.

downward/upward search will start. It will play
when a station is found.

Programming preset stations

•  To store a station: Select a band (if needed);

find a station by automatic tuning. Then press
MEM/

 button and rotate VOLUME knob to

choose a memory position (1-6), and finally
press MEM/

 button to confirm.

•  To recall a station: press repeatedly

/

 buttons until the needed station is found.

Auto memory store

Select a band, press and hold AS/PS

button to enter auto store mode. The radio will
automatically store 6 stations to the 6 preset
memories of the current band. To stop auto
store, press this button again.

  During auto station preset, the unit will

search and store stations with the strong signal
first, and then weaker signal stations until the
memories are full.

Preset scan

Select a band, press AS/PS button to scan

all preset stations in the memories of the
current band, each preset scan for 5 seconds.
To stop preset scan, press the button again.

RDS function

RDS (Radio Data System) service availability

varies with areas. Please understand if RDS
service is not available in you area, the following
service is not available, either.

AF (Alternative Frequencies)

function

Press and hold SEL button to select AF.

Rotate VOLUME knob to set this function on/
off. If the AF function is on, the display will
show “AF”.

When the radio signal strength is poor,

enabling the AF function will allow the unit to
automatically search another station with the
same PI (Program Identification) as the current
station but with stronger signal strength, so that
