19

13 cm 2-way coaxial acoustic system

•   If it is necessary to cut steel, reinstall

the cosmetic panel in place and use the hole
you have previously cut as a template. This
will help to insure proper cutting and a good
fit. Now, mark the locations for the speakers
mounting screws, remove the panel and drill
the screw holes. When finished you may
replace the panel.

•   After cutting and drilling all holes, inspect

the mounting areas for any metal burrs or
rough edges. File any area that may interfere
with the mounting of the speaker.

•   Clean any metal shavings from the

mounting area and check for areas in which
water may enter the speaker cavity. Treat the
area for water protection when necessary.

Securing the speaker

•  Position the speaker into the mounting

hole and reconfirm the correct mounting
location and hole placement.

•  Screw clips are provided to ensure a

snug fit. These should be placed over the
metal surface and line up the hole you have
previously drilled with the screw clip. Place
the speaker into the hole, align the holes and
proceed to insert the screws. Be sure to tighten
the screws evenly so that it will not warp the
speaker frame.

•  Turn your system back on and confirm

the speakers operation first at a low volume
and then you may increase the volume as you
desire.

•  After installation acoustic system and

having tested it the speaker grill will have to be
inserted. Turn on you system and follow these
steps carefully:

-  locate the speaker grill;
-  now carefully inspect the place where the

speaker grill will be mounted – there should be
no blowholes;

-  fix the speaker grill by screws.
