11

Operation

General operations

Touch screen

Due to the touch screen, you can fulfill most

functions not only by pressing buttons but also
by touching the options you need.

Turning the unit on/off

Press the POWER Button to turn the unit on.

When the unit is on, press the POWER Button
once to turn the TFT off. During TFT off, the
video out signal will be available so that the
connected monitor will show the screen of the
unit. Press the POWER Button again to turn
the TFT back on. Press and hold the POWER
button again to turn the unit off..

Reset the unit

Operating the unit for the first time or after

replacing the car battery, you must reset the
unit. Press reset button on the unit with a
pointed object (such as a ballpoint pen) to set
the unit to initial state.

  When some errors occur on the display,

you can also press reset button to resume to
normal, and it will erase the clock setting and
some memorized functions.

Setting the sound characteristics

• Volume: Use the VOL +/- Button to adjust

the volume level. Turn the button clockwise to
increase the volume, and vice versa. The larger
the number of volume, the higher the volume
level. You can also adjust the volume by sliding
the volume icon on top of the screen.

• Bass: Press the SEL Button on the RC

until the display shows “BAS”. Use the VOL +/-
Button to adjust. When EQ is ON, bass control
is not available.

•  Treble: Press SEL Button on the RC until

the display shows “TRE”. Use the VOL +/-
Button to adjust. When EQ is ON, treble control
is not available.

• Balance: Press SEL Button on the RC until

the display shows “BAL”, then use the VOL +/-

Button to adjust the balance between the left &
right speakers.

• Fader: Press SEL Button on the RC until

the display shows “FAD”, then use the VOL +/-
Button to adjust the balance between the front &
rear speakers.

• Other Audio Settings: You can adjust other

audio settings like preset equalizer, loudness or
subwoofer ON/OFF by tapping the “EQ” icon on
the main menu, or on the control menu of other
audio/video play modes.

Mute function

Press MUTE button on the RC to turn off the

sound. Press the button again or adjust volume
to resume the sound output.

Mode selection

Press the MODE Button to cycle the Play

Modes between RADIO, BT (Bluetooth), USB,
SD and AUX in.

RCA output

The RCA Output is on the back of the

unit. (Refer to Wiring Diagram) This output is
for connecting amplifier, equalizer, or other
audio component that requires a pre-amp out
connection. (Red=Right, White=Left) Follow
the manufactures instructions for the audio
component that you are connecting.

AV in jack

The Video Output Jack is on the back of the

unit. (Refer to Wiring Diagram) This output (in
yellow) is for connecting monitor(s). You must
connect a monitor for car in order to play this
unit in another monitor. Consult your dealer for
any kinds of monitors that are suitable to use
in car.

Subwoofer

The Subwoofer Output is on the wire

harness. (Refer to Wiring Diagram) This output
is designet for connecting up to 2 subwoofers
to the unit. Follow the amplifier’s installation
instructions. You can turn the subwoofer on/off
by pressing the icon in the main menu.
