12

 | English

1 609 92A 3BD | (16.5.17)

Bosch Power Tools

cessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electric shock.



Keep hands away from the sawing range. Do not reach

under the workpiece.

Contact with the saw blade can

lead to injuries.



Apply the machine to the workpiece only when

switched on.

Otherwise there is danger of kickback when

the cutting tool jams in the workpiece.



Pay attention that the base plate 6 rests securely on

the material while sawing.

A jammed saw blade can

break or lead to kickback.



When the cut is completed, switch off the machine and

then pull the saw blade out of the cut only after it has

come to a standstill.

In this manner you can avoid kick-

back and can place down the machine securely.



Use only undamaged saw blades that are in perfect con-

dition.

Bent or dull saw blades can break, negatively influ-

ence the cut, or lead to kickback.



Do not brake the saw blade to a stop by applying side

pressure after switching off.

The saw blade can be dam-

aged, break or cause kickback.



Use suitable detectors to determine if utility lines are

hidden in the work area or call the local utility company

for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete

stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



Products sold in GB only:

 Your product is fitted with a

BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

Products sold in AUS and NZ only:

 Use a residual current

device (RCD) with a rated residual current of 30 mA or
less.

Product Description and

Specifications

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for making separating cuts and cut-
outs in wood, plastic, metal, ceramic plates and rubber while
resting firmly on the workpiece. It is suitable for straight and
curved cuts with mitre angles to 45 °. The saw blade recom-
mendations are to be observed.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Lock-on button for On/Off switch

2

On/Off switch

3

Thumbwheel for stroke rate preselection

4

Hex key

5

Vacuum connection

6

Base plate

7

Adjusting lever for orbital action

8

SDS saw blade receptacle

9

Guide roller

10

Saw blade

11

Contact protector

12

Cover

13

Handle (insulated gripping surface)

14

Splinter guard *

15

Screw

16

Scale for mitre angle

17

Lead for the parallel guide

18

Locking screw for parallel guide *

19

Parallel guide *

20

Centring tip of the circle cutter *

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Jigsaw

GST 700

Article number

3 601 BA7 0..

Rated power input

W

500

Stroke rate at no load n

0

min

-1

1 450 – 3 200

Stroke

mm

20

Cutting capacity, max.
– in  wood
– in  aluminium
– in non-alloy steel

mm
mm
mm

70
10

6

Bevel cuts (left/right), max.

°

45

Weight according to
EPTA-Procedure 01:2014

kg

2.1

Protection class

/

II

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
