9

CHArGING/BATTerIes

•  Charge battery only with the charger that is supplied with

the tool

•  Do not touch the contacts in the charger

•  Do not charge battery in damp or wet environments

•  When charging the battery, place the charger on a flat

non-flammable surface and away from combustible

materials

•  Do not expose tool/charger/battery to rain

•  Store tool/charger/battery in locations where temperature

will not exceed 40°C or drop below 0°C

•  Do not use charger when damaged; take it to one of the

officially registered SKIL Service Stations for a safety

check

•  Do not use charger when cord or plug is damaged; cord

or plug should be replaced immediately at one of the

officially registered SKIL Service Stations

•  Do not use battery when damaged; it should be replaced

immediately

•  Do not disassemble charger or battery

•  Do not attempt to recharge non-rechargeable batteries

with the charger

EXPLANATION OF SYMBOLS ON TOOL/CHARGER/

BATTerY

3

 Read the instruction manual before use

4

 Do not expose tool/charger/battery to rain

5

 Warning

! After switching off the tool the blade continues

to move for a few seconds

6

Pay attention to the risk of injury caused by flying

debris

 (keep bystanders a safe distance away from work

area)

7

 Only use the charger indoors

8

 Double insulation (no earth wire required)

9

 Fail-safe isolating transformer (the power source is

electrically separated from the transformer output)

0

 Automatic shut-off when charger gets too hot (thermic

fuse blows and charger becomes useless)

!

 Incorrect polarity of the charger connection could cause

a hazard (only charge the battery with the charger

supplied)

@

 Do not dispose of the charger together with household

waste material

#

 Do not dispose of the battery together with household

waste material

$

 NiMH technology provides more energy in a less

environment-polluting way

WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):

•  If for any reason the old plug is cut off the cord of the

charger, it must be disposed of safely and not left

unattended

•  Do not connect the blue (= neutral) or brown (= live) wire

in the cord of the charger to the earth terminal of the plug

Use

•  Charging battery

%

-  battery of new tools is not fully charged

!  remove battery A from charger B after charging

period has ended thereby lengthening the service

life of the battery

IMPORTANT:

-  after 3 hours the charging operation will be completed,

and the battery may be used,

even though the red

light may still be on

 (the red light may require more

than 3 hours to turn off)

-  while charging, the charger and the battery may

become warm to touch; this is normal and does not

indicate a problem

-  ensure that the outside surface of the battery is clean

and dry before inserting into charger

-  do not charge at temperatures below 0°C and over

40°C; this will seriously damage the battery as well as

the charger

-  do not remove battery from tool while it is running

!  a battery that is new or has not been used for a

longer period does not develop its full capacity until

after approximately 5 charging/discharging cycles

-  do not repeatedly recharge the battery after only a few

minutes of operation; this may result in a reduction of

operating time and battery efficiency

-  if you anticipate long periods of non-use for the tool, it

is best to unplug the charger from its power source

•  On/off safety switch

^

Prevents the tool from being switched on accidentally

-  switch on tool by first pressing safety switch C

2

 and

then pulling trigger switch D

2

-  switch off tool by releasing trigger switch D

-  move tool away from cutting area before switching off

!  after switching off the tool the blade continues to

rotate for a few seconds

•  Changing blades

&

!  remove battery from tool

!  wear protective gloves

-  turn tool upside down

-  push release button E

-  slide protective cover F in same direction as arrow

printed on cover and lift it from the housing

!  be careful when lifting the protective cover; the

shrub shear blade in particular may fall down

unexpectedly

-  lift blade G or H out and mount required blade as

illustrated

-  position protective cover F back and slide it towards

the blade until it snaplocks

•  Holding and guiding the tool

!  while working, always hold the tool at the

grey-coloured grip area(s)

*

-  maintain a stable working position

-  keep your other hand away from the cutting blades

•  Trimming hedges

(

-  trim the sides of the hedge first (from the bottom

upwards), then cut the top

-  trim the side of a hedge in such a way that it will be

slightly narrower at the top

-  use a hand saw or pruning shears to cut thicker branches

-  shrub shear blade H as well as grass shear blade G

can be used for trimming hedges

•  Trimming grass and shrubs

)

-  when cutting long grass, work in stages from the top

and take small cuts

-  for optimal cutting results, only cut dry grass

-  keep the tool away from solid objects in order to

protect the cutting blades against excessive wear

-  grass shear blade G can also be used for trimming

shrubs
