Braun CombiMax 750 - Инструкция по эксплуатации - Страница 5

5

Attaching the working bowls

The food processor bowl

7

 is operated

on the large drive place of the motor
block

1

. The chopper bowl

j

 is operated

on the small dirve place.

1. With the motor switched off, place
the respective bowl onto its drive place
matching the arrow on the bowl with the
arrow on the motor block (A).

Then turn the bowl in the «function»
direction until the lower fixed stop is
reached. The bowl on the other drive
place must be in the lifted position. If
the other drive place is free, put on the
protective cover

m

.

2. Put the attachment needed (see in-
structions for each of the attachments)
onto the drive shaft of the bowl and push
it down as far as it will go (B).

When inserting the blade

l

 onto the

chopper bowl

j

, push it down until it

audibly snaps in place.

3. Put the lid onto the bowl matching the
arrow on the lid with the arrow on the
bowl (C).

Then turn the lid clockwise guiding its
nose into the safety lock opening of the
motor block

1

 until it audibly snaps in

place.

N.B.
When attaching the lid

 of the chopper

bowl

j

, it must be provided with the

seal ring

.

Removing the working bowls

Switch off the appliance. Turn the lid anti-
clockwise and lift it off. Then turn the
bowl in the «click» direction until the
arrow on the bowl matches the arrow on
the motor block and lift off the bowl.

When removing the blade from a bowl,
take hold of it by the knob and pull it off.

Caution: The blades are very sharp.

The blade

n

 comes with a protective

cover. If not in use, store the blade in the
protective cover.

Cleaning

First, always switch off the motor and
unplug the appliance. Clean the motor
block

1

 with a damp cloth only.

All parts can be cleaned in the dish-
washer. If necessary, clean all parts
thoroughly with a spatula or a brush
before rinsing them.

Color-intensive food (e.g. carrots) may
leave stains on the plastic parts; wipe
them off with cooking oil before cleaning
with water.

For cleaning the lid

, first remove the

seal ring

. Put the seal ring back in

place after cleaning. You can use the
seal ring from both sides.
Do not use sharp objects for cleaning
purposes.

Clean the blades and the inserts very
carefully – they are very sharp.

Using the food processor
bowl

7

When using the food processor bowl,
always insert the required attachments
before adding ingredients.

1. Kneading

For kneading you can use the dough
hook

v

 or the blade

n

. For best results,

we recommend using the kneading hook
which is specially designed for making
yeast dough, pasta and pastries.

Yeast dough (bread/cake)

Max. 500 g flour plus other ingredients
Speed 6, 1

1

/

2

 minutes

Pour the flour into the food processor
bowl, then add the other ingredients –
except liquids.
Put on the lid

8

 and lock in place.

Then choose speed 6 and switch the
appliance on.
Add liquids by pouring them through the
filling tube of the lid while the motor is
running.

When kneading with the blade

n

, do

not add ingredients like raisins, candied
peel, almonds, etc. which are not
supposed to be cut. These have to be
added manually after having taken the
kneaded dough out of the food processor
bowl.

Pasta dough

Max. 500 g flour plus other ingredients
Speed 6, 1

1

/

2

 minutes

Pour the flour into the food processor
bowl, then add the other ingredients –
except liquids.
Pour the required amount of liquid
through the filling tube in the lid when
the motor is running.

Do not add any liquid after the dough has
formed into a ball as then the liquid will no
longer be absorbed evenly.

Pastries

Max. 500 g flour plus other ingredients
Speed 6, approx. 1 minute

Pour flour into the food processor bowl,
then add the other ingredients. For best
results, be butter used must not be too
hard, nor too soft.

Put on the lid

8

 and lock in place. Choose

speed 6 and switch on the appliance.

Stop kneading the dough shortly after a
ball has formed. Otherwise the pastry
dough will become too soft.

8

6

4

2

14

12

10

pulse

off/0

CombiMax 700

1

2

1

2

6

6...14

6...14

6...14

 2...  4

 2...  8

A

pulse
off/0

B

pulse
off/0

1

1

2

C

11

11a

11

11a

3202302_K700_IAM  Seite 5  Donnerstag, 23. März 2006  1:48 13
