Braun CombiMax 750 - Инструкция по эксплуатации - Страница 4

4

Our products are engineered to meet
the highest standards of quality,
functionality and design. We hope you
thoroughly enjoy your new Braun
appliance.

Important

•

The blades

l

/

n

are very sharp!

Take hold of the blades by the knob
only. After use, always first remove the
blades from the bowls

7

/

j

 before

removing the processed food.

•

Make sure that your voltage corre-
sponds to the voltage printed on the
bottom of the appliance. Connect to
alternating current only.

•

Keep the appliance out of the reach
of children.

•

This appliance was constructed for
household use only to process the
listed quantities.

•

Do not use any parts in the microwave
oven.

•

Make sure to avoid touching the
running drives with your fingers. Put
on the protective cover

m

 whenever a

drive place is not in use, since both
drives rotate simultaneously when
switching on the appliance.

•

Do not allow the appliance to operate
unsupervised.

•

Braun appliances meet applicable
safety standards. Repairs on electric
appliances must only be done by
authorized service personnel. Faulty,
unqualified repair work may cause
accidents or injury to the user.

•

The cord of the appliance may only
be replaced by an authorized Braun
Service Center, because a special tool
is required.

•

Switch the appliance off and
disconnect it from the mains before
storing it.

Specifications

•

Voltage/wattage: See typeplate on
the bottom of the appliance.

•

Operating time and max. capacity:
See processing instructions.

Description

The Braun CombiMax with the 2-bowl
system meets highest demands for
kneading, mixing, blending, chopping,
slicing, shredding and grating, both
simply and quickly.

To obtain best results, two different
working bowls are available: a large
food processor bowl

7

 and a small

chopper bowl

j

.

Thus, for chopping, puréeing or mixing
you can choose between the large and
the small working bowl. Moreover, you
can use the small bowl to prepare the
food which then can be further processed
in the large bowl (e.

g. to chop nuts for a

nut cake dough). Only one bowl can be
operated at a time.

1

Motor block

2

Cord store

3

Motor switch (On = I, off = off/0)

4

Pulse mode «• pulse»

5

Variable speed regulator (2–14)

6

Safety lock (avoids simultaneous
operation of both working bowls)

7

Food processor bowl (2 l capacity)

8

Lid for food processor bowl

7

9

Pusher for lid

8

j

Chopper/mixer bowl for small quanti-
ties (0.75 l capacity)
Lid for chopper bowl

j

Seal ring for lid

l

Blade for chopper bowl

j

m

Protective cover for motor drive when
bowl has been taken off

Attachments for food processor
bowl

7

(Important: Not all attachments will be
included in the standard equipment of all
models).

n

Blade for food processor bowl

7

with protective cover

o

Insert carrier

p

Fine slicing insert – a

q

Coarse slicing insert – b

r

Fine shredding insert – c

s

Coarse shredding insert – d

t

Grating insert – e

u

French-fries system

v

Plastic or metal kneading hook
(depending on model)

w

Whipping attachment

Note: Before using the food processor for
the first time, clean all parts as described
under «Cleaning».

Overload protection

In order to avoid damages caused by
overload, this appliance is equipped with
an automatic security switch which shuts
off the current supply if necessary. In
such case, turn the motor switch

3

 back

to «off/0» and wait approx. 15 minutes
to allow the motor to cool off before
switching on the appliance again.

Pulse mode «• pulse»

4

The pulse mode is for example useful for
the following applications:

•

Chopping delicate and soft food, e.g.,
eggs, onions or parsley.

•

Carefully folding flour into dough or
batter to maintain the creaminess.

•

Adding whipped eggs or cream to
more solid food.

The pulse mode «• pulse» is activated
by pressing the green knob on the
motor switch

4

 with switch setting

«off/0».

Before activating the pulse mode, set
the desired speed with the speed regu-
lator

5

. When releasing the green pulse

knob

4

, the appliance is switched off.

Recommended speed
ranges for individual
attachments

Set the speed range by means of the
variable speed regulator

5

. It is recom-

mended to first select the speed and then
switch on the appliance in order to work
whith the desired speed right from the
beginning.

Attachments

Speed range

Kneading hock

6

Blade

l

and

n

6–14

Whipping attachment:
– egg-whites

5

– cream

3

Slicing, grating and
shredding inserts

2–8

French-fries system

2–3

(please also refer to product printing)

Working with the 2-bowl
system

Only one working bowl can be
operated at a time.

The working bowl which is not used must
be in the upper position or additionally,
can be turned in the «click» direction
where it is locked in place. When the
arrow markings are aligned, the bowl can
be taken off. For safety reasons, always
put the protective cover

m

 onto the free

drive shaft after a bowl has been taken
off.

Double safety feature:

The appliance can only be switched on
when the desired working bowl with lid is
properly engaged. If the lid is opened
during operation, the motor switches off
automatically. As in this case the motor
switch

3

 is still on «I», turn it back to

«off/0» to avoid switching on the motor
accidentally.

11

11a

11

English
