www.timberk.com • Electric air conditioner

10

Fig. 5

Fig. 7

Fig. 6

FAN button

Pressing this button can set fan speed circularly as: auto (AUTO), fan1(    ),

fan2 (        ), fan3 (           ), fan4(               ), fan5 (                   ), infinite fan.

     button

Press this button the up&down swing function can be started and canceled.

The remote controller defaults to static swing condition.
Press «MODE» button and «    » button at the same time when remote

controller OFF to switch between simple swing and static swing.
In static swing condition, pressing button, the swing angle of up & down

louver changes as below:

       button

Rotate button blinds left / right in this series do not used «Health» button

-to activate the mode in this series do not used
Press «MODE» button and «

» button at the same time at remote

controller OFF to switch between simple swing and static swing.
In static swing condition, pressing button, the swing angle of left & right

louver changes as below:

When selecting «    » with remote controller, it’s auto swing. Vertical louver

of air conditioner will swing up&down automatically at the maximum angle.
When selecting «

» position swing. Vertical louver

of air conditioner will stop at that position as shown by the icon to swing.
When selecting «      », it’s the circulating swing. Vertical louver of air conditioner

will swing circularly according to the angle as shown by the icon.

NOTE:

In AUTO speed, air conditioner will select proper fan
speed automatically according to ambient temperature.
Fan speed under dry mode is fan1.
After entering the infinite fan speed mode, users can
adjust the fan speed according to the button «    » or «   ».

NOTE:

When selecting «    » with remote controller, it’s auto
swing. Horizontal louver of air conditioner will swing
up&down automatically at the maximum angle.
When selecting «

 » with remote controller

swing. Horizontal louver of air conditioner will stop at that
position as shown by the icon to swing.

NOTE:

There is no this function for the units. If press this
button, the main unit will sound, but it also runs under
original status.

 No display

 No display
