Timberk AC TIM 07H P4 - Инструкция по эксплуатации - Страница 10

www.timberk.com • Electric air conditioner

10

9. TROUBLESHOOTING

Trouble

Cause

Troubleshooting method

The air conditioner is not switched on

when Power button is pressed

The tank fill-up
indicator is flashing, the
condensate collection
tray is filled up

Drain water from the tray

Actual room temperature
is higher than the set one
(in heating mode)

Set the temperature correctly

The air conditioner switches in heating

mode

Automatic overheating
protection is tripped.
The unit is switched off
in case the outlet air
temperature goes higher
than 70°C

Wait until the air conditioner cools
down and switch it on again

Loud noise or strong vibration

The air conditioner is
installed on an inclined or
unsmooth surface

Install the air conditioner on a
smooth horizontal surface

A noise, resembling a gurgle of water

Noise emerges due to
refrigerant flow in pipes

It is normal

Trouble

Cause

Troubleshooting method

E1

Short circuit on a
temperature sensor or a
processor board

Contact an authorized service
center

E2

Short circuit between
a copper pipe of the
temperature sensor and
the processor board
wiring

Contact an authorized service
center

E4

It indicates the tank is
filled up with water or
the plug is connected
incorrectly

Remove the rubber plug, located
at the bottom of the unit, and
drain water. Then check it the
plug is connected correctly.

Error codes for LCD-display models

11. SERVICE LIFE

12. UTILIZATION RULES

Service life of the appliance is 10 years provided that the respective

installation and operation rules are observed.

Date of the conditioner manufacture is shown in a serial number of the

device. For more details, please, ask a shop assistant.

Upon expiration of the service life, the appliance should be utilized in

accordance with norms, regulations and procedures effective in the

place of utilization.

10. TRANSPORTATIOM AND STORAGE

Temperature

requirements*
Humidity

requirements*

We are exploring new technologies and we constantly improving the quality

of our products. That’s why specifications, design and accessories are

subject to change without any specific notice.

* This product must have storage in dry, well-ventilated space of warehouse

at the temperature not lower than -30°.

Transportation and

storage

From -30° to +50°

From 15% to 85%

(without a condensate)
