12.

Electric  air conditioner (split system)

EN

Dehumidifying operation

Ensure the unit is plugged in and power is avail-

able. The OPERATION indicator on the display
panel of the indoor unit starts lashing.
1. Press the MODE button to select DRY mode.
2. Press the UP/DOWN buttons to set the

desired temperature. The temperature can

be set within a range of 17OC~ 30OC in 1OC

increments.

3. Press the ON/OFF button to start the air

conditioner.

Adjusting air low direction

Use the SWING and DIRECT button to adjust
the desired airlow direction.
1. When push the DIRECT button, the horizontal

louver changes 6 degree in angle for each
push.

NOTE: On some models operate swing feature

instead of this feature.

2. When push the SWING button, the louver

will swing up and down automatically.

NOTE:

In the Dehumidifying mode, you can not switch thefan speed. It has

already been automatically controlled.

Fig. 5

Fig. 6

1
2

1

2

3

speed

temp

mode

memory

timer on

swing

direct

ion

sleep

timer off

clean

maxi

climate control

speed

temp

mode

memory

timer on

swing

direct

ion

sleep

timer off

clean

maxi

climate control
