JetStream L2/L2+ Managed Switch

21

Configuration

■

Use the console port to access the switch. When using the console port, start the terminal emulation

program (such as the Hyper Terminal) on the PC and configure the terminal emulation program as

follows:

Baud Rate

Data Bits

Parity

Stop Bits

Flow Control

38400 bps

8

None

1

None

For the detailed configurations, refer to the

User Guide

 and

CLI Guide

. The guides can be found on

the download center of our official website: https://www.tp-link.com/download-center.html

Note:

For certain devices, you may need to change the password the first time you log in, which will

better protect your network and devices.

4.3  Controller Mode

Controller Mode applies to the large scale network with mass devices. All devices can be centrally

configured and monitored via Omada Hardware Controller or Omada Software Controller.

Note:

Before the following configurations, make sure the switch can access the internet. When using

Omada Software/Hardware Controller, make sure the switch and the controller are in the same

subnet.  Typically,  the  switch  obtains  IP  address  from  the  DHCP  ser ver.  You  can  check  the

switch’s IP address on the DHCP server.

■

Via Omada Hardware Controller (OC200/OC300)

Omada Hardware Controller (OC200/OC300) is a good alternative if you have no spare PC to keep

running Omada Software Controller in the network. It needs to be purchased additionally. Follow the

steps below to configure the Omada Hardware Controller.

Figure 4-2

Manage the network via Omada Software/Hardware Controller

Switch

Router

Clients

Omada Hardware Controller

(OC200/OC300)

EAP

EAP

EAP

Note:
