ENGLISH

TOUCHSCREEN INTERFACE

Our interface and its buttons light up intuitively way to facilitate the use of the machine and
to guide you.

Light status

Meaning

Unlit button

The corresponding function is not selected/is
not accessible.

Press the pulsing light (dimly lit with
long flashes)

An action with the selected function is in
progress

Press the flashing light

An action is in progress

Lit button/bright light

The function is selected

INTUITIVE WARNING LIGHTS

Your machine is equipped with intelligent technology to make daily life easier. The machine
automatically detects and controls the levels of coffee beans, water and ground coffee.
When these containers must be filled or emptied, a warning light will notify you.
If maintenance is required, the “warning” LED

 appears on the touchscreen interface and

one or more of the three light bars will be lit:

GETTING STARTED

INSTALLING THE APPLIANCE

Switching on and preparing the machine

Danger:

Connect the appliance to a grounded 230 V socket. Otherwise, you expose
yourself to fatal injuries due to the presence of electricity!

Respect the safety information in the “Safety information” leaflet.
Priming the machine allows the water circuits to be filled, so that the machine can operate.
Preheating and automatic rinsing will take place.

Intuitive warning light

Action to be performed

Water container (U)

The water tank is almost empty, it must be refilled. See 7

– REFILLING THE WATER TANK fig 1 to 7.

Coffee bean container (V) The coffee bean container is almost empty, it must be refilled.

See 8

– REFILLING THE COFFEE BEAN CONTAINER, fig 1 to 8.

Coffee grounds collector
(W)

The collector is filled with coffee grounds, it must be emptied.
See 9

– EMPTY THE COFFEE GROUNDS COLLECTOR, fig 1 to 5.

OVERVIEW

Overview of the control panel:

Button

Description / General Functions

Turn the machine on and off.
A beep sounds each time the “ON/OFF” button is pressed.

Select a drink. The selection is backlit.

Select the steam function in order to foam the milk to make a milk-
based drink manually. The selection is backlit.

Press before drink selection to increase or reduce the coffee strength,
by modifying the amount of ground coffee. You have 3 possible
choices, from weak to strong. The selection is backlit with 1 to 3
beans.
Press before drink selection to increase or reduce the volume of the
drink, by modifying the volume of water used. You have 3 possible
choices, from a small to large drink. The selection is backlit with 1 to 3
drops.

Start or stop the current drink.

This warning icon appears on the control panel when there is a
problem linked to the machine’s operation. For example, when there is
no water, coffee beans or maintenance is required.

Press before drink selection to make double the amount. The selection
is backlit with 2 cups.

Allows access to the maintenance functions: rinsing, cleaning and
descaling. The relevant maintenance function is backlit.

Accesses the “Favourite” menu and your saved favourites / After
a drink is made, it allows you to save a favourite. You can save 2
favourites: A and B. The selected favourite A or B is backlit.
