Do not reach into the soft stop mechanism. Fingers may be
trapped when the door is closed.
Please observe the specific information in the other
sections:
DANGER
identifies a situation involving direct
danger which, if not obviated, may
result in death or severe bodily injury.
WARNING
identifies a dangerous situation
which, if not obviated, may result in
death or severe bodily injury.
CAUTION
identifies a dangerous situation
which, if not obviated, may result in
minor or medium bodily injury.
NOTICE
identifies a dangerous situation
which, if not obviated, may result in
damage to property.
Note
identifies useful information and tips.
3 Controls and displays
3.1 Operating and control elements
Fig. 3
(1) Alarm button
(8) SuperFrost button
(2) SuperCool button
(9) Temperature display
(3) On/Off button
(10) HomeDialog symbol
(4) Alarm symbol
(11) SuperCool symbol
(5) Menu symbol
(12) Child-proofing symbol
(6) Down setting button
(13) SuperFrost symbol
(7) Up setting button
3.2 Temperature display
The following are displayed in normal operation:
-
the average cooling temperature
The following displays indicate malfunction. Possible causes and
corrective action (see Malfunction).
-
F0
to
F9
4 Putting into operation
4.1 Changing over the door hinges
You can change over the door hinges if necessary.
WARNING
Risk of injury and damage due to pieces of broken glass!
The glass door is heavy. If it falls or there is impact on the glass
edges, the glass pane may shatter.
u
Protect the door properly when detaching it!
u
Detach the glass door working in a team of two.
u
Put the door down on a soft mat.
Ensure that the following tools are to hand:
q
Torx 25
q
Torx 15
q
Screwdriver
q
Cordless screwdriver, if necessary
q
A soft mat
4.1.1 Detaching the upper soft stop mechanism
Fig. 4
u
Open the upper door.
NOTICE
Risk of damage!
If the door seal is damaged, the door may fail to close properly
and the cooling will be inadequate.
u
Do not damage the door seal with the screwdriver!
u
Disengage and remove the faceplate
Fig. 4 (1) using a flat-
blade screwdriver.
w
The faceplate is attached over the soft stop bracket.
Fig. 5
u
Slide the faceplate forwards over the soft stop bracket
Fig. 5 (4) in the direction of the appliance.
u
Snap the accompanying safety lock
Fig. 5 (2) into the oblong
hole.
w
The safety lock prevents the hinge from snap-closing.
u
Using a screwdriver, detach the cover
Fig. 5 (5) on the hinge
side as far as the first detent.
w
The pin becomes visible.
u
Press the pin
Fig. 5 (3) out from underneath.
u
Press the soft stop bracket
Fig. 5 (4) towards the door.
u
Fully detach the cover
Fig. 5 (5) on the hinge side and remove
it.
u
Remove the faceplate
Fig. 5 (1).
Controls and displays
4
