EN - 38

3.2 Display and Control Panel

5

6

8

9

2

1

7

11

10

12

4

3

Using the Control Panel

1. Menu button to activate economy mode

2.  Enables the temperature value to be

changed in the fridge compartment and

allows the super cooling mode to be

activated. The temperature value for the

cooling compartment can be adjusted

to 8, 6, 5, 4, 2

o

C, or SC.

3. Enables the temperature value to be

changed in the freezer compartment

and allows the super freezing mode to

be activated. The temperature value

for the freezer compartment can be

adjusted to -16, -18, -20, -22, -24

o

C,

or SF.

4. Mode selection / Confirmation button

5. Temperature adjustment indicator for

the fridge compartment

6. Super cooling indicator

7. Temperature adjustment indicator for

the freezer compartment

8. Super freezing indicator

9. Holidey mode symbol

10. Economi mode symbol

11. Child Lock symbol

12. Alarm / Service call symbol

3.3

Operating your Fridge Freezer

Lighting (If available)

When the product is plugged in for the

first time, the interior lights may turn on 1

minute late due to opening tests.

After the appliance is plugged in, all

symbols will appear for 2 seconds, then the

start-up values will appear as -18

°C on the

freezer setting indicator and +4

°C on the

cooler setting indicator.

All buttons on the control panel are touch-

operated (only press to activate the button

you want to operate).

3.3.1

Super Freeze Mode

How to Use

•

Press the freezer temperature setting

button, then the “OK” button until the

letters SF are displayed on the freezer

compartment display. You will hear a

beeping sound and the mode will be

active. If the "OK" button is not pressed

within 9 seconds after the SF letters are

displayed, the previously selected freezer

temperature will be activated.

•

When this mode is selected, the letters

SF will be displayed on the freezer
