13

Plodder

K28 / KW30 / KW55

-Warm up period is complete
- Load is turned off
WARNING:  Electric  shocks  cause  injuries  with  potentially  fatal  consequences.  The  power  generator  must  not  be  connected  to  other
electric supply systems (e.g. public supply systems) or electrical generation systems (e.g. other power generators). You may connect the
load with earthing type plugs (220V alternating current).

Proceed as follows to connect a load to the shockproof socket:
1 . Lift cover.
2. Insert shock-proof plug.

Load calculation

For normal operation of the generator it’s necessary to calculate the load according to the parameters of the consumers. According to the
types of loads all consumers can be divided into 2 groops:

ACTIVE (ohmic)
This consumer generates electric energy into warm. It doesn’t produce in-rush starting current (requirement of current doesn’t exceed
normal level when turning on).

Example:

 filament lamps, electric heaters, household equipment, small appliances (irons, blow dryers, teapots, toasting ovens); electric

instruments (computers, TV, office equipment);
REACTIVE (inductive)
Construction consists of electromotors that consume the energy at the time of start by several times more (produce in-rush starting cur-
rents) than during the main operation (rate power).

Example:

 electrical tools (fretsaws, electric drills), gardening equipment, pumps, air compressors,welders.

Reactive consumers consume part of energy for the generation of electromagnetic fields. Index of measure of this part of consumable
