19 Specifications

19.1

STIHL RM 4.0 RTP Lawn

Mower

–

Engine type: Kohler HD775

–

Displacement: 173 cm³

–

Power: 2.6 KW (3.5 hp) at 2800 rpm

–

Speed: 2800 rpm

–

Maximum fuel tank capacity: 1400 cm³ (1.4 l)

–

Weight: 44 kg

–

Cutting width: 53 cm

19.2

Blade

–

Minimum thickness a: 2.5 mm

–

Minimum width b: 55 mm

–

Sharpening angle: 30°

19.3

Sound Values and Vibration

Values

The K value for the sound pressure level is

2 dB(A). The K value for the sound power level is

2.2 dB(A). The K value for the vibration value is

1.20 m/s².

–

Sound pressure level L

pA

 measured in accord‐

ance with EN ISO 5395-2: 79 dB(A)

–

Guaranteed sound power level L

WAd

 meas‐

ured in accordance with 2000/14/

EC / S.I. 2001/1701: 93 dB(A)

–

Vibration value a

hv

 measured in accordance

with EN 12096, EN 20643, EN ISO 5395-2,

handlebar: 2.40 m/s²

For information on compliance with Employers'

Vibration Directive 2002/44/EC and

S.I. 2005/1093, see www.stihl.com/vib.

19.4

REACH

REACH is an EC regulation and stands for the

Registration, Evaluation, Authorisation and

Restriction of Chemical substances.
For information on compliance with the REACH

regulation see www.stihl.com/reach.

20 Spare Parts and Accesso‐

ries

20.1

Spare parts and accessories

These symbols indicate original STIHL

spare parts and original STIHL acces‐

sories.

STIHL recommends the use of original STIHL

spare parts and accessories.

Despite ongoing market observation, STIHL is

unable to judge the reliability, safety and suitabil‐

ity of other manufacturers' spare parts and

accessories; accordingly, STIHL cannot warrant

for the use of those parts.
Original STIHL spare parts and original STIHL

accessories are available from STIHL dealers.

20.2

Essential Spare Parts

STIHL assumes no liability for injury to people or

damage to property resulting from the use of

unauthorised attachments or spare parts.

–

Blade: 6383 702 0100

–

Blade fastening screw: 9008 319 9075

–

Washer: 0000 702 6600

21 Disposal

21.1

Disposing of the Lawn Mower

Information on disposal is available from a STIHL

specialist dealer.

► Dispose of the lawn mower, blade, petrol,

engine oil, accessories and packaging in

accordance with regulations and in an environ‐

mentally friendly manner.

22 EC Declaration of Con‐

formity

22.1

STIHL RM 4.0 RTP Lawn

Mower

STIHL Tirol GmbH

Hans Peter Stihl-Strasse 5

6336 Langkampfen
Austria
declares under our sole responsibility that

–

design: lawn mower

–

manufacturer's brand: STIHL

–

type: RM 4.0 RTP

–

cutting width: 53 cm

–

serial number: 6383

complies with the relevant provisions of Direc‐

tives 2000/14/EC, 2006/42/EC, 2014/30/EU and

2011/65/EU and has been developed and manu‐

factured in accordance with the versions of the

following standards valid on the date of manufac‐

ture: EN ISO 5395-1, EN ISO 5395-2 and

EN ISO 14982.
Approved body involved:

TÜV Rheinland LGA Products GmbH

Tillystrasse 2

90431 Nuremberg, Germany
